As with many hobbies, there must be a certain level of preparedness to achieve exemplary results. Preparedness requires the tools needed to do the job. In clock repair, one can get by with very few tools at minimal expense or, one can spend thousands of dollars.
Does one require anything beyond the basics tools for clock repair?
Clock repairs can be done with the most basic tools obtained at any hardware store. Additional tools such as let down keys, mainspring collars, and reamers can be sourced at a relatively modest cost from clock part suppliers. For a couple of hundred dollars investment, you are well on your way to clock repair.
Tall case clock stand
Are expensive tools necessary for clock repair? No. Can a mainspring be removed and reinstalled into a barrel without special tools? Yes. Can an open mainspring be restrained without specialized collars? Yes. Can bushing work be done without a Swiss-made bushing machine? Yes. Many procedures can be done with very basic tools. I know because that is how I started nearly 10 years ago.
As I explored clock repair I began to realize that I was ready to take the plunge. I have acquired specialized tools such as a spring winder, mini lathe, ultrasonic cleaner, and a bushing machine. They are pricey and I did not purchase everything at once, spreading the cost over time and buying as I could afford them. The first was a spring winder, followed by a bushing machine, a mini lathe, and finally an ultrasonic cleaner (replacing a cheap unit).
Spring winder, 2015Bushing Machine, 2016Mini-lathe, 2019Ultrasonic cleaner, 2018
Then, there is all the other stuff; a staking set, soldering iron, paints, and paintbrushes, clock oils and applicators, mainspring clamps, screws, bolts, bushings, washers, utility lamp, micro drill, cutting and smoothing broaches, high-speed micro drill bits, pliers, screwdrivers, and other assorted hand tools.
I could go on but my point is this; as one delves deeper into a hobby (any hobby for that matter) one learns that there are special tools that make the job easier and more efficient and those tools do not necessarily have to be expensive or the highest quality. In fact, buying used is a sensible option.
Pivot locatorElectric micro drill
My advice is that anyone starting out repairing and servicing locks should proceed with caution and hold off buying any expensive equipment until they are sure that they are committed to pursuing clock repair as a hobby or business.
Tick-Talk Tuesday is about the letters and comments I have received from you, the reader, concerning your clock, issues you might have had, challenges you face or a clock you would like me to profile or my responses to your questions with advice on your particular clock concern. For those comments and questions that stump even me, I consult within my clock circles for the best possible answer
LG writes,
“Dear Mr.Ron:
I came across this vintage mini clock by Sonoo-Ron in a leather pouch. I cannot find anything about it and thought this must be very unique and if interest to you? If you are not interested, but know something about it, would love to know more!
Sender’s photo
Thank-you so very much!
Regards, LG”
Sender’s photo
My reply,
“I must confess that I have never heard of the name which I believe is Sonochron. What I found interesting is that the clocks were used by bomb-makers in Europe.
The electro-mechanical travel alarm clock from the 70s is from the Schwarzwälder Müller-Schlenker watch factory in Schwenningen.
The alarm clock is the following size: 70 mm length, 33 mm height and 25 mm depth.
The clockwork is mechanical, the alarm electrical. Due to its construction, it was very popular with a left-wing extremist terrorist group, the “Revolutionary Cells” (RZ). The possibility of separating the clockwork and buzzer means that the alarm clock can be converted into a time fuse for bombs. It was used in the RZ bombings. In 1985, the Federal Criminal Police Office had the remaining stock of Sonochron alarm clocks marked in order to track down future attackers. They could only be bought in selected shops that were equipped with video surveillance by the police. This action sparked a heated debate about state interference with personal rights, because all buyers were monitored. The alarm clock was a hot topic of conversation.
I originally assumed this clock was a Seth Thomas since it had a Seth Thomas movement. After a thorough search on the web, I concluded that this was not a Seth Thomas case. I searched for clocks made by other clockmakers, starting with E.N Welch, Ansonia (because it is similar in style to the Syria), Gilbert, Sessions and finally Waterbury. The term “Waterbury cabinet clock” generated some hits. I found one on an auction site then, two more. I now have a case made by a different maker than the movement and in clock circles this is called a marriage.
The case is a Waterbury model called the “Wren”. I found three Wren models, two with paper dials and one with the identical dial pan as this clock. It may well be that this dial pan is original to the case.
Despite the fact that it is a marriage I might keep it. The case is attractive and the movement fits the case, although both the centre hole and regulator hole over the 12 look to have been bored out and not in a tidy way.
The dial has been cleaned and repainted.
Cleaned and repainted dial
Now to the case. It Stands 13 1/8″ Tall By 12 5/8″ Wide And 5 1/2″ deep. As of this writing if you search for this model you might see one or two without the top crown. It is easily detached and no surprise that it might go missing.
Crooked finial
The case is in good shape with no parts missing however, the top finial on the right is not correctly aligned with the bottom column which I did not notice till I began cleaning the case. Evidently it had detached in the past and a past repairer glued it back not noticing the misalignment. It was simple matter of prying the finial off, regluing and centering it.
Two other pieces had to be reglued, a support piece for the crown and crosspiece in the back for one of the sides of the crown.
I cleaned the case with Murphy’s soap and following the scrubbing I decided that there was enough shellac worn off that a fresh coat would make the case much more appealing.
Finial is reattached and straighter
New coat of shellac
I applied traditional shellac, mixing amber flakes and alcohol with a broad artists brush. In the next shot you can see the difference between the left side of the crown and the right. I now have the option of leaving the finish as-is or aging it by “dulling” it with 4X0 steel wool.
Crown section
In the next photo is the completed case.
To me it is a huge improvement.
All this is being done while the movement is undergoing testing and once the testing is complete the two, the case and the movement will be “married” again.
Now if I can find the matching glass and bezel it will be complete.
It might sound a little strange to use a paint roller on a clock dial. This is not just any paint roller but one specifically designed for the purpose. The candidate is a embossed dial pan for a Waterbury Wren shelf clock C.1895.
Most of the paint has been rubbed off the dial over the years which you can see in the photo below.
Should the dial be left as-is or retouched? It is an age-old clockmaker’s dilemma. We all have our views but I tend to take the position that if it is grimy and unsightly and takes away from the look of the clock it should be cleaned and retouched.
I decided to start from scratch. I knew that if I immersed the dial in my ultrasonic cleaner with the heat setting on I would risk stripping away all paint from the numbers and that is exactly what happened.
The cleaning also took off a thick layer of grime and dirt leaving a much brighter dial.
Dial as found
Hand painting is an art and a steady hand means the difference between a homemade job and one close to the original factory application. I used a multi surface water-based acrylic satin black paint, one I often use for clock dials, hands and so on.
Here is the dial just out of the ultrasonic cleaner. All paint has been released from the embossed areas. The ultrasonic solution was black and had to be discarded.
The paint roller is made out of 18 gauge wire and masking tape, specifically made for this job. I added a strip of double-sided tape to the roller to allow a rough surface so that the paint could adhere.
A homemade paint roller
The roller worked reasonably well over the embossed dial and it was certainly a lot faster than hand painting. Excess paint was removed from the dial with a Q-tip and toothpick.
Using a Q-tip to clean excess paint
I used the roller for the chapter ring as well. After rolling there were some touch-ups and an artists brush #2-0 was used for areas the roller could not reach.
Artist’s brush
I allowed the paint to dry and scraped off the excess.
Inpainting nearly complete
I am very pleased with the results. Here is a before and after shot of the dial.
BeforeMovement yet to be installed
It is not factory perfect but from a reasonable viewing distance it is difficult to tell it was repainted plus, it looks much more presentable.
Now, to find a 5 1/2 inch bezel and glass to complement the dial.
One more shot is what it deserves. It had been running fairly well since I serviced it three years ago it but in the last few weeks it has decided to run for about 5 minutes and stop and I think I know the reason why.
Ansonia Drop Extra wall clock
This Ansonia Extra Drop time-only Rosewood veneered wall clock was manufactured in the early 1880s by what was then known as the Ansonia Brass and Copper Company.
The brass dial bezel is the only significant part missing. Minor items such as the verge, hands, pendulum bob, suspension spring/rod, and the drop access door were easily sourced. I made the drop access door later on.
Here is an article I wrote in 2018 wherein I assess the case and movement for the first time. At the time I was challenged by the prospect of putting a rusty old movement back in running condition and giving it a new life.
It was in poor condition when I bought since it literally came out of a barn and it is just pure luck that it runs at all.
The symptoms? If wound halfway it would run 3-4 days and stop. If wound tight it would not run at all because surface rust and other contaminants caused the coils to bind together. This is very typical of old clocks that have not been running for years. A movement that is “overwound” is a myth. It is the combination of old oil, rust and dirt that seizes the mainspring.
Rusty mainsprings
For some clockmakers any rust on a mainspring means that is it tossed it out because the mainspring is inherently weaker. This particular mainspring has surface rust on the outer two coils and rust on the edges of the spring. Otherwise, it has no cracks or splits and has plenty of power.
Yes, it was seized
Generally, to remove rust, repairers often apply a liquid gel, black tea, or even use electrolytic rust removal.
If I were in the business of clock repair, I would certainly replace the mainspring and pass the cost on to the customer. However, the original mainspring is part of the history of the clock and I don’t think the amount of rust is enough to prevent me from reusing as long as it is cleaned properly. As far as I am concerned, replacing a mainspring is the last resort.
Servicing yet again
Now that I have it apart why not throw the parts into the ultrasonic for a good cleaning. After everything was dry I inspected the parts, polished the pivots, and pegged the pivot holes.
I released the mainspring but this is how it came out of the case
I gave special attention to the mainspring. After inspecting it (yet again) I used a Brillo pad, steel wool and a microfiber cloth to eliminate the roughness as much as possible.
Ansonia mainspring cleaned up and ready for installation
Following the cleaning I applied a thin film of Keystone mainspring oil. I then reassembled the movement and oiled it prior to placing it on the test stand.
Ansonia movement on the test stand
While on the stand I gave the mainspring a few turns, put the movement in beat and it ran well for a couple of days which is what I expected.
On day 4, it was time for the ultimate test, to wind it fully till it winds no further. I was hoping for a good result and it ran the full 8-day cycle. The mainspring just might be “clean” enough that it will now run without stopping.
I will monitor the results of this little experiment for a while longer but for now things very good.
About a year ago I picked up two clocks. I had my eye on one, an Arthur Pequegnat Canuck shelf clock, and the other was “thrown in” as part of the deal. We completed the transaction on the Pequegnat clock and the seller asked me if I wouldn’t mind looking at a mantel clock stored on a shelf in his garage. He said, “for $10 more you can have this”. I did not know the make at the time but for $10, why not! It was in sad condition as you can see in the next photo.
Fleet clock with a worn finish
A tin plate affixed on the back of the clock told me what it was made by the Fleet Time Company of Montreal (Canada).
Many of these clocks were sold at department stores across Canada during the pre-war (WWII) era. However, this little-known Canadian clock company had a brief life span. Between 1936 and 1940 the company produced a range of two and three-train mantel clocks with movements sourced from Germany but were forced to end their operations when the war began.
Fleet Time Co. label
The Second World War took a heavy toll on this company as the source of movements dried up and so did the company’s fortunes.
Wood cases were made in Canada for some models while other cabinets were imported from Germany.
Servicing the movement
I had completed work on the case a few months ago and now it is time to service the movement.
3 train Fleet movement by Gufa
The clock has a Gufa Westminster chime movement. Gufa is the Guetenbacher Uhrenfabrik, located in Gütenbach, Germany. They manufactured 400-day clocks, cuckoo-clocks and later they became the “Jahresuhrenfabrik” (August Schatz & Sons in Triberg, Germany). Gufa is not a name horologists come across very often in North American. There is a chime gear patent date number ending in 34 which likely refers to the year 1934 indicating manufacture between 1935 and 1939. It is a solid, well-built movement.
Assessment of the movement
I had replaced the time mainspring shortly after I bought the clock but I knew that I would eventually have the movement on the workbench. As is typical of German clocks of this period in that the mainspring barrels can be removed without dismantling the movement, so, replacing the time mainspring was an easy fix.
The clock was running, though not well. On the fourth or fifth day, the chimes (and strike) would stop though the time train would soldier on a few days more. Wear issues on the strike and chime train had to be addressed.
I disassembled the movement, put the parts into the ultrasonic cleaner, and discovered afterwards that the plates had been lacquered. With the ultrasonic heat setting on, the lacquer stripped off but not uniformly. As it is a $10 clock I am not concerned about aesthetics.
Fleet movement wheels tied together according to location
To eliminate the chance that I would mix up the wheels for the 3 trains, I tied each set together. Once out of the ultrasonic cleaner I untied them and placed them in their respective trays. Westminster chime movements have similar-looking gears in the three trains and it is best to separate them to avoid frustration during re-assembly.
After inspecting the movement I determined that new bushings were required on the second wheels plus the motion works arbour. Three of the second wheels on the backplate, one bushing for the strike side second wheel front plate, and one for the motion works for a total of 5 new bushings; not bad for a 3-train movement. These are the typical wear points on three-train movements as the second wheels handle the greatest load.
Bushing work
Once the pivot holes were pegged out and the wheels rechecked in their locations, the bushing begins. Aside from the second wheels, most other pivot holes were in good shape. I don’t often use bushings with an outside diameter of 4.50mm but this movement required 4 in total. All bushings had to be reamed out with a cutting broach followed by a smoothing broach. All wheels were test fit with the plates together and things looked good.
Reassembly
Next is reassembly. With so many wheels it is a bit trickier than a two-train movement but it is important to work slowly and carefully to avoid a bent pivot. Once the wheels are positioned, test each train to check that everything is in place. After the nuts are tightened, the remaining parts such as the locking plate, chime locking lever, warning lever, rack snail, mainspring barrels and so on are installed/attached.
Testing
Of all movements, three trains are the most difficult to set up correctly. Although all three trains spin independently they are interconnected by levers. In order for everything to function in unison, careful attention must be paid to the job of each lever, what it does and how it performs its function every 15 minutes.
Gufa movement, front plate showing rack, snail, levers, and so on
Everything went fairly smoothly. Both the strike side and chime side go into warning as they should, the locking plate stops the chime at each quarter-hour including the hour, which is a good sign the locking hook on the chime train is in the correct position.
Gufa movement on the test stand
The chime strike lever is, however, sticking on the strike warning pin. Without taking the movement apart I used 1600 grit memory paper to smooth the hook end surface where it meets the strike warning wheel pin. The polishing allowed it to function a little better but continued testing revealed that that solution did not work. I finally had to remove the chime strike lever and polish the hook. the polishing was successful.
The next issue is the strike paddle which is ending the strike sequence hanging off one of the star points. The plates on the strike side must be opened up and the paddle repositioned. For safety reasons and to preserve the mechanism should things go awry, the power is let down on all mainsprings. Adjustments such as these come with the territory as nothing should be expected to work perfectly the first time.
Gufa movement, the upper wheel is the main chime wheel
After the aforementioned adjustments are made, next is the chime sequence and that means loosening the set screw for the main chime wheel and rotating the drum till the quarter strike is at the 1-2-3-4, the beginning of the sequence.
Once the adjustments have been made it is back to the test stand.
Okay, my strike paddle adjustment did not work but in the meantime, the testing of the movement proceeded and everything looks very good at this point. I will give it a few days and return to re-adjusting that paddle.
Everything is working now.
I’ll be honest, 3 train movements are not my favorite type to work on for 4 reasons. One, they often need major work only after a few years. Secondly, it is often not enough to install new bushings for worn pivot holes lower in the trains but to address other worn holes up the trains, as well. Thirdly, they are labour intensive and finally, except for modern movements, parts are almost impossible to find.
In many cases, certainly as far as a modern Hermle is concerned, it is often more cost-effective to simply replace the movement rather than repair it.
If you are a collector or simply have a general interest in mechanical clocks and wish to sell antique and/or vintage clocks then, read on. I am not a seller but I purchase clocks to build my collection.
I occasionally sell clocks locally as a way to manage my collection. Most of the clocks I’ve sold have been serviced by me, and my main goal is to recover the time spent on cleaning and repairs, rather than promoting sales on my blog.
Mauthe buffet clock C. 1950
The Difference between Antique and Vintage
Let’s begin with definitions. Antique is anything over 100 years old and vintage is less than 100 years but more than 30 years old. Anything that is less than 30 years old may be considered vintage but more often it is called collectible. Try to pass off a 30-year-old clock as an antique and you will turn off a lot of prospective buyers.
Miniature one-weight Vienna wall clock C.1870
Clock Terms
When selling a mantel clock, it’s important to use ‘mantel,’ not ‘mantle.’ A mantel refers to a shelf or structure, while a mantle is something one wears. Using the correct terminology also signals that you have a deeper knowledge of clocks than the average person.
A clock with two winding points (with some exceptions) is typically referred to as a striking clock, which strikes but does not ‘chime.’ A chiming clock usually plays a quarter-hour melody, such as Westminster or Whittington, and often has three winding points (though there are exceptions). There is no such thing as a ‘Tempus Fugit’ clock; ‘Tempus Fugit’ simply means ‘time flies in Latin.
A grandfather clock is a clock that stands 6 feet or taller and is not a wall clock. A grandmother clock is a floor clock that measures less than 6 feet in height. Grandfather clocks are also known as tall-case clocks, longcase clocks, or hall clocks.
Gingerbread and parlour clocks are distinct in design, but both are typically classified as kitchen clocks.
There are many other styles but let’s leave it at that.
Honesty and Disclosure
In my view, the most important element in selling a clock is honesty.
Inform the prospective buyer by describing as much detail as possible about the clock without getting too wordy. A clock that is a marriage, a case with a similar but replacement movement, should be stated as such. Replacement glass, newer dial, replacement crowns and finials, case repairs, or full case restoration should also be disclosed, perhaps not immediately in your ad but as a follow-up.
If the clock is running and was recently serviced by a competent repair person, state such in your ad. If the clock is running but the movement requires cleaning it should be stated as such. If it is not running explain why and what issues it might have such as a broken mainspring, missing pendulum bob, missing winding key, and so on. If you don’t know why it is not running, say so but be honest about it.
If you’re selling a clock and don’t know much about it, be honest and say so. Similarly, if you’re selling clocks in general but lack knowledge about them, it’s better to be transparent about that as well.
If your clock is rare, indicate why it is rare and support your claim with credible documentation including its provenance.
E. Ingraham shelf clock C.1878, not rare but uncommon
Establishing a Value
Research auction prices to get a feel for the value of similar clocks that are offered for sale and the price realized. Sources are Kijiji, Facebook Marketplace, eBay, and any number of respectable auction houses.
There will be a range of prices and something in the middle of the range is a good guide though its condition will determine what people expect to pay.
Determining the condition of a clock is an important factor in evaluating its value. The clock’s overall appearance, functionality, and any repairs or restorations it has undergone will all impact its worth. A clock in poor condition generally has a lower value than one in excellent condition, as potential buyers may factor in the cost and effort required to restore it.
Know that a clock is only worth as much as someone will pay. If you price your clock too high you will know it soon enough.
Rare and desirable clocks, as well as clocks with an interesting provenance, will command higher prices.
Clocks also vary in price according to the geographic location where they are sold. Generally, clocks that are made in the same location as the clock is sold will command higher prices. English and German bracket clocks are not as popular in America as they are in Europe and are priced accordingly.
Preparations for Sale
A clock in running condition will fetch a higher price than one that is not. A professionally serviced clock in excellent running order will command an even higher price. A clock case cleaned of grime will present better than a dirty one. Missing hands or dial glass will adversely affect the price. Items such as these can be replaced and parts are available from clock suppliers but it becomes an extra cost for the buyer and for many, it is a deal-breaker.
If you are handy at clock repair, servicing the movement or any case repairs will enhance the value of the clock you are selling. If you have serviced a clock, always be clear about the work you’ve done. Describe in detail the specific repairs, cleaning, or adjustments you’ve made to the movement, as well as any parts that were replaced or restored.
This transparency not only helps potential buyers understand the value of the clock but also assures them that the clock is in good working condition. Whether it’s oiling, replacing worn parts, or correcting any mechanical issues, providing this information builds trust and demonstrates your expertise.
The term servicing has many definitions. Be wary as sellers may claim a clock has been serviced if the only thing done to it is oiling. Among reputable clock repairers, servicing is defined as, taking the movement out of its case, disassembling the movement, cleaning the parts, addressing wear issues/repairs/parts replacement, reassembly, oiling, and testing before reinstalling it back into the case.
Sessions Raven time and strike shelf clock
Visual Presentation
While few cell phones (though some are improving) can capture highly detailed images of a clock, they often suffice for many purposes. However, blurry or out-of-focus photos are unacceptable.
Smiths Enfield mantel clock serviced and ready for its new owner
Several images from different angles as well as a photo of the inside of the clock case are much more helpful than one photo. During the daylight, place the clock near a window and position yourself between the window and the clock to take a series of photos in natural light. If there is damage or wear take close-up photos of those areas.
In general, a dedicated camera with artificial light will produce better results than a cell phone camera.
Clock Description
Crafting an ad is an art in itself. You must be concise and accurate and not overly wordy. There is a balance between too little and too much information. Less information means fewer inquiries from prospective buyers. Too much information with technical terms will turn off prospective buyers. Try to anticipate the questions prospective buyers might have in order to limit the number of follow-up queries.
State the clock’s maker if known, the model if possible, the year it was made, the type, (time-only, time and strike, chiming clock), the style of clock (mantel, wall, shelf, parlour, Ogee, tall-case, etc.). as well as any interesting features, for example, a steeple clock with an alarm function or a clock with a second’s hand. Along with your description state the approximate age. If you do not know, a picture of the maker’s mark on the dial or the movement will assist prospective buyers.
While it’s not necessary to give a reason for selling, doing so can sometimes enhance the ad.
1860s era Seth Thomas column and cornice shelf clock
Where to Advertize
There are a number of ways to sell a clock. Facebook Marketplace is very popular. Other local online for-sale sites, eBay, flea markets, consignment shops, and auction houses are popular places to sell a clock. Setting up an account for most online sites is a pre-requisite but there is usually no cost.
Mauthe wall clock circa 1899
Example of a Poor Ad
Antique clock, comes with key, $250
Example of an Eye-catching Ad
Scaling down my collection. Antique German time and strike clock made by Friedrich Mauthe, circa 1899. Completely serviced in 2019 which includes disassembly and addressing worn parts. Original glass, mild refresh of the case, new wall stabilizers, and new arch piece. Ran for many years in a family home in Parsboro, Nova Scotia. Runs well and keeps good time, original key supplied. $250
Juba Schatz time and strike mantel clock
Final Remarks
While selling a clock can be a frustrating experience, it can also be quite satisfying. I choose to sell locally to avoid shipping costs and the risk of items arriving damaged. Meeting the buyer in person allows me to answer any questions they may have and provide a more personal experience.
Though this is not a definitive guide to selling, I hope these pointers and ideas will help when you decide to sell (or buy) your antique or vintage mechanical clock.
Tick-Talk Tuesday is about the letters and comments I have received from you, the reader, concerning your clock, issues you might have had, challenges you face, a clock you would like me to profile, my advice on your particular clock concern or a general clock question. For those comments and questions that stump even me, I consult within my clock circles for the best possible answer
CL writes:
“Hi Ron,
I was hoping you could help me identify a clock I purchased at an estate sale this weekend for $10. The back of the wall pendulum clock has a intact paper label with a full size standing Ostrich and the letters H H S N. Stamped on the workings is 45/100 and 27583 It is a 4 chime clock.
That is all of the identifying marks.
Any information you have would be helpful.
I did find one post on a site called Worth Point about a clock that had HHS N (Hermann Heinrich Straussj of Nurenberg)
STORAGE AUCTION FIND IN UNIT I WON IN AUCTION! If you search journeymagazine on eBay’s Discussion boards under Watches, Clocks & Timepieces I asked about this antique clock movement with the initials HHS N – and got 2 responses. First is a link that shows HHS N is a very rare clock movement that was part of the historical clock & watch exhibition in Nuremberg 1905 (Below)The 2nd is a link to a Mauthe that had HHS N clock movement in it.A VERY RARE CLOCK MOVEMENT FOR THE COLLECTOR OUT THERE!NOTE: I don’t have a key + I don’t know clock movements, so I don’t know if it works – Ask Any Questions or for more Photos – SOLD AS IS!FROM LINK GIVEN ME ON DISCUSSION BOARD: H.H.S.N. was a mark for the firm of Herm.[ann] Heinr.[ich] Strau [ =ss], of N rnberg. The only information in Abeler’s _Meister der Uhrmacherkunst_, the standard ref. for clockmakers in the German speaking tradions, is “erw. Hist. Uhrenauustell., N rnberg 1905.” In other words, they were mentioned in some connection with the historical clock & watch exhibition in N that year (in celebration of the 400th anniversary of the invention of the pocket watch (so they said) by Peter Henlein aka Petrus Hele. There were lots of firms represented, new and old clocks exhbited, etc. There’s a dozen or so small-print pages on this exhibition in several issues of the 1905 _
Thanks for your time.”
My reply:
“Hi CL
Thank you for coming to my blog.
This is a German “box” clock style from the late 1920s. The letters HHSN stand for Hermann-Heinrich Strauss, Nürnberg. Strauss in German means Ostrich. This company were clock dealers who are thought to have used Mauthe movements (and others) in their clocks. They went out of business in the late 1920s. Your clock could have been made by almost any of the big German firms at the time, Mauthe, Kienzle, Junghans etc. The movement looks like a Mauthe and that makes perfect sense. 45 refers to the length in centimetres of the pendulum (17.7 inches) while the number 100 refers to the beats per minute. 27583 is a production number and the first two digits are likely the year the clock was made.
4 -rods mean the movement will produce a very nice bim-bam strike if the hammers are aligned correctly on each of the strike rods.
It is a clock worth preserving and a steal for the price you paid.
Hope this helps
Ron”
CL replies:
“Ron,
Thank you for this knowledge! I appreciate the quick reply. I look forward to getting it cleaned and hung on our wall.”
The past year has been like nothing we have ever experienced in our lifetime. Routines, relationships and plans were upset and with them major adjustments have had to be made. The situation is improving day by day, folks are re-establishing their routines, the country is opening up and things will no doubt return to normal in the months to come and with it a new definition of normal.
How will future generations define this dark period of our lives?
The lake our Shangri-La
It is time to relax, slow down and for my wife and I that means a change of scenery as we travel to our cottage in central Canada to spend the summer season with friends and family. Our get-away plan for the summer is to relax with a few good books, do a little fishing, swimming, hiking and exchange stories with friends and neighbours over a glass (or more) of wine.
Since many of my articles have been written well in advance of the summer months there will be NO interruption in blog posts through the summer months. I will continue to maintain a steady output of 7 to 9 clock blog articles per month.
An Ansonia cottage clock with the dial removed for testing and spaghetti for lunch
Keep those cards letters coming as 1960s TV variety host Dean Martin used to say. There may be a slight delay returning your email inquiry or responding to blog post comments but rest assured that question(s) about your clock or comments regarding any of my posts are important to me and will be answered.
Roasting marshmallows
This blog profiles my own clock collection, the challenges of maintaining and repairing clocks, the joys of finding new and interesting vintage and antique clocks plus many articles of horological interest.
As we explore central Canada I will no doubt find interesting clocks as we scour antique stores, flea markets and junk shops. New clock stories, new repair challenges and perhaps the next major restoration project will also be part of my journey this summer.
Canadian Clock Museum, Deep River Ontario
Included will be a trip to The Canadian Clock Museum in Deep River, Ontario to discover new and interesting clocks added to their collection and chat with curator Allan Symons.
Use the search box to browse past articles and/or click “follow” to have clock articles brought to your mailbox every three to four days. I hope you enjoy reading them as much as I enjoy researching each and every article.
This is the model 2038 with a bim-bam strike or what Gilbert called a Normandy Chime in its sales catalog. The model number along with the words “Normandy Chime” are stamped on the bottom of the case. The “Normandy Chime” was reminiscent of the old bells of Normandy (Corneville) in France.
Gilbert tambour clock
In terms of nomenclature within clock circles, calling it a “Chime” certainly adds to the confusion as this would be considered a striking clock rather than a chiming one.
The movement has been serviced
Clocks such as this that have not seen servicing in many years fail because of a combination of bushing wear and old oil buildup.
The movement was cleaned, the mainsprings serviced, pivots polished, 5 bushings installed to address wear issues and tested prior to returning it to its case.
Gilbert movement with a date stamp of 1925
The door catch
Although serviced well over a year ago I never got around to repairing the door catch. I could not figure out a way to make an effective catch and I don’t think the solution I came up with is the best possible one.
Now, you might think, why is this such a big deal? It’s not, but without the catch the door pops open a little and will not stay closed, enough to annoy the heck out of me.
Brass tab fashioned into a catch
The solution, for now, is a brass tab with a hole drilled through it to accommodate one of the bezel screws. It is not perfect but allows the door to close securely.
Front glass and bezel of Gilbert clock
I have no idea what the original catch looked like but evidently it was a poor enough design that it broke at some point in the clock’s history.
The clock is promised as a gift and now I am now assured that everything works properly.
Tick-Talk Tuesday is about the letters and comments I have received from you, the reader, concerning your clock, issues you might have had, challenges you face, a clock you would like me to profile, my advice on your particular clock concern or a general clock question. For those comments and questions that stump even me, I consult within my clock circles for the best possible answer
Clock for sale
MB wrote
“Hi Ron,
I came across this clock and your blog and have fell in love with it. I want to put a bid on it but have no idea what it is worth. Could you give me your opinion please?”
I am not sure whether they fell in love with the clock or my blog!
I replied,
Attached photo
Hi and thanks for writing.
The clock you wish to bid on appears to be American-made and from the 1990s. Let me point out some factors to consider.
If the clock is from the 1990s, the movement (the mechanical works) have reached the end of its service life. Typically movements from this era have a life span of about 25 years. If it is a non-working clock, it is worn out. If it is a working clock there is not much time left on the movement. Regardless, to service or replace the movement would be in the order of $450 to $500. If it has been recently serviced (disassembled, wear issues addressed, repairs made, reassembled, tested and oiled) or the movement has been replaced with a new one, that is a big plus.
From the photo I would question why the weights are at different levels. In a working clock the three weights descend together (with slight variations) through the clock’s 8-day cycle. See attached photo (right).
Many years ago it was not unusual to spend $2000 to $3000 for one of these clocks when new. Today they are worth almost nothing. The fact that this clock appears to be in a basement or garage does not bode well for its condition. The photo is not very clear but I can see wear around the base of the clock and it may even be missing the bottommost pedestal (which might be concealed by something in front of it) which also begs the question: what else is missing?
A similar clock in excellent condition with a recently serviced movement would be in the $500 price range.
A clock, such as this, that has never been serviced whether working or not would be in the $100 – $125 price range but be prepared to spend more money on it unless you can do the repairs yourself.
MB writes back,
“Thank you so much! They did indicate that the pendulum isn’t working so I guess I will stay away.
I appreciate your detailed answer and for saving me from what sounds like it could have been a waste.
I was attracted to the style of this clock but disappointed when I learned that it was a marriage of a Waterbury case with a Seth Thomas movement. Briefly, a marriage is when parts from two different makers come together.
Buying a clock from a flea market, antique mall, a shop or what have you is always a gamble. On this particular clock there is no trademark or name on the dial or a label in the back of the case that told me who the maker was. I made an assumption and it was an impulse buy.
Glass and bezel are from a later clock
While at the antique store I opened the back of the case to confirm that the clock had a movement and it was complete with pendulum bob and coiled gong and to me everything appeared correct until I brought it home. My first thought was an Ansonia movement when I looked at it under the dim light of the store.
Seth Thomas and other makers made similar cabinet style cases but this is the Wren by the Waterbury Clock Company. Being a marriage, the clock is worth much less to those particular about such matters. No matter, it looks attractive.
I can imagine a past owner’s conversation with the repair guy, I don’t care what you do, just make it work! And the repair guy responds by removing the very worn Waterbury movement and replacing it with a Seth Thomas. Easy peasy!
One of the current seller’s stickers on the case said it was a non-working clock but with minor adjustments, such as moving the pallets closer to the escape wheel and releasing the time-side mainspring, I had it running in no time. There is not much wrong with the movement and a good cleaning plus a bushing or two should put things right.
So, what did I buy?
As I said, I like the case and it has a decent movement but when a clock is a marriage one can expect some questionable repairs and interesting changes as one takes things apart.
I am not absolutely certain the dial pan came with the case or was added later but the glass and bezel are certainly from a mid-century mantel clock. It is so ugly it will be tossed into the spare parts drawer. I will keep the dial pan but a piecrust bezel with flat glass is more appropriate for the period.
Piecrust dial on a 6-column mantel clock
Seth Thomas time and strike 8-day movement
I removed the dial and discovered a number of extra screw holes here and there, varying lengths of screws, some screw holes filled with pieces of wood, even a couple of Robertson screws (not invented until after the First War) and so on. Obviously the replacement movement required new holes and why not drill a few extra holes for good measure!
The hole on the dial just above the 12 is larger than it should be. It was either enlarged to accommodate the regulating arbour or it’s a new hole altogether.
On a positive note both the case and the movement are from a similar period.
Disassembling the movement
But this post is about servicing the movement.
I am impressed with the engineering of this Seth Thomas movement. It is robust and well-designed though it has an interesting, overly complicated, speed regulating feature.
From my research I found that the hip style movement is the type 44 which was used for a 12 year period beginning in 1890. In 1903 it was presumably replaced with the type 89 movement, simpler to manufacture, fewer parts and more reliable, and appeared in many thousands of ST mantel clocks afterwards. It has a sickle shaped brass piece between the plates so that the clock can be turned backwards repeatedly at the hour to sync the strike with the hands. It is technically called a set-back counter weight.
Brass piece indicated by arrow
Regulating arbour with worm gear on one end
There were variations of this movement, front winding movements as opposed to rear winding, with and without the worm gear speed regulator and some with stop works. This movement does not have Geneva stops.
It took me more time than usual to pry open the plates because I was slowed down by the intricacy of regulating mechanism. Part of the mechanism consists of a long arbour that passes from the front plate to the back plate. At one end is a worm gear and on the other is the regulating end. It is secured to the outside of the front plate by means of a spring with a pin through the arbour. To release the arbour, the pin must be pulled and the spring releases.
Well, actually the spring flew across the room. No problem, I’m used to crawling on the floor looking for clock parts.
I have worked on a lot of American time and strike movements but this type of regulating mechanism is a first for me. In fact, the set-back counter weight is also a first for me.
Analysis of the movement
The movement has had 12 bushings installed, 5 on the front plate and 7 on the back. The work is well done but I don’t like the arrows scratched into the plate indicating where each bushing would be installed. I use a Sharpie pen and after I have completed the bushing work I wipe the marks off with alcohol. There is no need to mar the plates.
Arrow indicating scratch mark below bushing
After looking over the movement carefully I can see there is enough wear in some bushings that they must be replaced, both second wheels, front plate, the governor, both front and back and the escape wheel bridge bushing which for some reason has punch marks around it, the only unsightly repair.
Escape wheel and bridge
The mainsprings look to be in good shape and still bears the original ST trademarks. No worn gear teeth and the pivots, plus the lantern pinions are all in great shape.
All in all, not bad for a movement that was last serviced quite a number of years ago.
Strike side of ST movement
The pivots were polished and next is the bushing work. Two were interesting to say the least.
The count count wheel and the strike pin wheel are side by side. A bushing was required for the pin wheel but I could not access it from inside the plate. This is one of those few times when drilling from the outside is the only way however, I was able to push the bushing home from the inside plate. It is one of those situation where you have to stand back, analysis the problem and consider a strategy. It worked.
The second was the escape wheel bridge. To stabilize the bridge a 5-step block jig comes in handy. Otherwise, it is very difficult to keep the bridge steady and drill a straight hole.
% level job block used for an escape wheel bridge
The drilling went fine until the last 3.47 mm cutter. When I began to drill out the hole the old bushing came out. I knew right away that the new bushing would not have a tight fit. Evidently a past repairer had the same problem.
staking set
The block from a staking set is a useful tool. With it I was able to lay the plate down on it and punch the bushing from the inside to stabilize it.
Once together everything fell into place or so I thought. Unfortunately, I will have to take it apart again because I forgot the regulating worm gear which can only be installed with the plates separated. The movement will run perfectly fine without it, but it is part of the clock.
How far do you go repairing, restoring or conserving a vintage or antique clock without changing it in a significant way?
My daughter. a civil engineer raised the philosophical argument that questions whether an object like a clock that has had all of its components replaced remains fundamentally the same object. This paradoxical thought exercise is called the Ship of Theseus. Plutarch, a Greek philosopher, asked whether a ship that had been restored by replacing every single wooden part remained the same ship.
The ship wherein Theseus and the youth of Athens returned from Crete had thirty oars, and was preserved by the Athenians down even to the time of Demetrius Phalereus, for they took away the old planks as they decayed, putting in new and stronger timber in their places, in so much that this ship became a standing example among the philosophers, for the logical question of things that grow; one side holding that the ship remained the same, and the other contending that it was not the same. Plutarch, Theseus[2]
Think about it! If something is fundamentally changed is it the same object?
One of our proud provincial symbols in Nova Scotia is a sailing ship called the Bluenose II, our provincial ambassador. The original Bluenose was a fishing and racing schooner that ran aground and sank 90 years ago. To honour the original Bluenose, the Bluenose II was built in the 1960s and sailed for over 50 years until it was determined that she was not seaworthy.
Bluenose II, Peggy’s Cove (photo, NS government, used for educational purposes)
In 2018 the hull of the Bluenose II was rebuilt with new materials. Some items such as rigging, masts, sails, ironwork, deck structures, safety equipment, and electronics were reused. Part of the timeline for future repair involves replacing the masts, sails, rigging, and deck structures. Will the ship retain its identity? To purists, no! To Nova Scotians, yes!
Let’s go beyond the nautical example and apply our example to the lantern clock.
The lantern clock is a clock with a lantern-shaped brass case made for about a century after 1630 or so. Most had one hand, all were weight-driven with a bell on top and sat on a wall bracket. They were the first type of clock widely used in English private homes in the 17th century. Eventually, the lantern clock became obsolete when tall case clocks came into fashion.
Converted lantern clock
Lantern clocks are highly collectible today and those that are in “original” condition are the most desirable. But, almost all of them have been altered, even those considered “genuine”. Check out this quote from a sellerof lantern clocks, D. and J. Benson, who are specialists in early English clocks.
We are strong believers that if a clock was converted to a different escapement many years ago, this should be retained, being part of the history of the clock, rather than reconverting clocks back to former guises. Only under compelling circumstances would a clock be returned to a former state. Only absolutely necessary restoration work is carried out in order that the original clock survives for future generations. We conserve rather than replace. D& J Benson
“Compelling circumstances”. Important provenance, perhaps?
Early conversions were from verge to anchor escapement. Later ones had the original movements removed and a fusee movement (single or double) installed. When converted, original movements including alarm mechanisms were taken out, a single-hand was replaced with two hands (or the minute hand added), broken finals and door handles might have replaced, chapter rings re-silvered, doors lost due to their nature of lifting out easily. Therefore, what is the nature of the clock after it has been changed, and how original is it? Does it retain its identity? To purists, no! To the casual collector, yes!
Let’s see how this philosophical argument plays out:
If too much is done to restore a clock is it fundamentally the same and is it considered original even though new parts were made from the same materials using the same methods when the clock was first made?
Do changes or alterations to the clock that bring it back to its original look and function including the making of new parts make it more “original”?
If one replaces one part at a time on a clock so that at some point all parts are replaced, at what point does a clock no longer become the same clock?
If you take all of those parts and make a “new” clock which of the two clocks is original? What is the nature of the clock’s identity since no two objects can occupy the same identity?
This is the dilemma of identity. One more example!
In 2016 I acquired my first weight-driven Vienna Regulator clock. As I worked on the clock I began to realize that many parts were replaced over the years such as the brass bezel, hands, glass panels, weights, and even the movement. Although the changes were part of the history of the clock I began to accept the notion that it is what it is and to a casual observer, it looks authentic.
Gustav Becker Vienna Regulator
Minimal Invasive Intervention
The term minimal invasive intervention means how far do you go to repair, restore or conserve a clock without changing it in a significant way? Some say that any work performed on an antique clock would diminish its value. Going too far to repair a clock and it begins to lose its attraction and value as a collectable object.
Is a “true collector” more interested in a movement that has never been worked on or one that has been repaired or restored? While it is always desirable to have a running clock most concede that to make a movement actually work, intervention must be accepted (bushing and pivot reconstruction, for example). The question remains; if I want the clock to function, what is the least I can do without changing it in a significant way?
Repair, Restoration, Conservation
Repair; to rectify the faults of a clock in a way that might alter it from its original form (gear replacement, pivot work, bushing work, replacement of some parts)
Restoration; the reconstruction of the movement and clock case to original condition.
Conservation; the protection of a clock using any methods that prove effective in keeping that article in as close to its original condition as possible for as long as possible.
Any amount of intervention is frowned upon by some collectors while some amount of intervention is not only necessary but desired by others and while collectors are always searching for a completely untouched clock, an antique clock in pristine condition that has never been meddled with is a rare find.
Questions, questions, questions…
Is undoing the “damage” caused by a previous poor repair an overly invasive procedure?
If the repair was done shortly after the clock was made and it was a proper repair, was clearly documented as markings inside the clock case, should it be left untouched? (example, a wheel that has a rough tooth repair but functions well). Is the poor repair part of the clock’s historical provenance and should it be left as-is?
Would bringing the movement back to its original state be considered a restoration or a repair?
Will a repair enhance or decrease the value of the clock?
Is a repair or restoration a form of conservation?
My position regarding changes to a clock
My goal is a functional clock that presents well. A non-working clock must become a working clock because that is the nature of its existence. If a clock has important provenance and extensive repairs to the movement and/or case alter it in a negative way and I will leave it alone. But I will always clean a clock case (unless otherwise directed) because as one clockmaker I know put it, “isn’t patina just another word for dirt!”.
When working on a customer’s clock I recommend presenting several options regarding the repair of the movement and addressing case issues. This past year I worked on a customer clock and asked what they wanted to be done. It had a beautifully designed case but a non-functioning movement. Make the clock run they said and replace the broken hands but don’t touch the case even though in my view the case could have used a good cleaning and a fresh coat of shellac. I did what was requested. Is the customer right? Yes!
I will leave you with two examples.
Ingraham Grecian
Ingraham Grecian
The bob wire that came with a clock appears to be a section of coat hanger wire. Replace it with a proper adjustable bob wire?
On a movement with pinned plates one of the pins is a finishing nail. Replace it with a brass taper pin?
Hell, yes on both counts!
In some circles, this trivial examples like these will provoke a heated argument. Is there a correct answer? Put twelve clockmakers in a room and you will have a thirteen opinions.
Let me begin by saying that I am not a big fan of clock movements with steel plates. Many that I have come across have brass bushing inserts that I believe to be a limitation rather than a benefit.
Waterbury short drop wall clock
The movement in this plain drop octagon case is a Waterbury time-only. When I bought the clock in January of 2016 it came without the glass and bezel which I ordered from a supplier. I was informed by the previous owner that it had been serviced so, other than the new glass and bezel plus inpainting some of the numerals I have done nothing else to it, but now it is time to service the movement.
Inpainted numerals
A diminutive size, this clock was made around 1930 just a few short years before the Waterbury Clock Company was placed in receivership.
It is a solid oak case measuring 19 inches long by 12 inches wide, with an 8 inch paper dial marked Waterbury, a black and gold pendulum aperture, and 8-day time-only movement. The bottom of the dial says, ” Made in the USA by Waterbury Clock Company”, Connecticut. These clocks are often refereed to as schoolhouse clocks though I can’t imagine the dial of a clock this small visible from the other end of a classroom.
Issues with steel plated movements
As mentioned, the movement has steel plates. Steel plates are perfectly fine and I understand why manufacturers use them, to save brass (and money), but I have two issues with them.
One, no matter how hard I try, I cannot get them to shine because the steel tends to attract tarnish which is almost impossible to remove. And of course, as they are made of steel they are prone to rusting. The solution is to plate the steel in brass or nickel as some makers did.
Arthur Pequegnat movements, with steel plates, for example, are nickel-plated. Unless the nickel plating is compromised they shine up spectacularly.
Pequegnat nickel-plated steel plates
A second issue with steel plates is the brass bushing inserts. In my view, there is simply not enough brass to work with. In most cases I use a smaller bushing than I would otherwise employ so as to avoid cutting into the steel plate. I use the Bergeon bushing system. KWM bushings may have a smaller outside diameter, I’m not sure?
Large bushings on a movement that has steel plates means there is a risk in cutting into the steel. The cutters that came with my Bergeon bushing machine are about $35CDN apiece and it would only take a cut or two into steel to render them dull and useless.
Waterbury Arion instructions
Assessing the movement
The movement is in generally good condition. The lantern pinions and gear teeth are in excellent condition. There is minimal wear on the pallets, escape wheel teeth and all parts in general.
The mainspring is definitely a replacement. The loop end looks to have been annealed. It does not look professional but the mainspring is in very good shape and is reusable. I suspect, given the length of the mainspring, that it is oversized for the movement.
The movement is certainly in need of bushing work. New bushings will extend the life of the movement.
Five bushings were installed. Two on the verge, front and back, the third wheel back plate and second and fourth wheels front plate.
Three bushings on the front plate
The pivot on the third wheel is 2.30mm in diameter. Though it would normally require a 4.50mm outside diameter bushing, a 4.50mm bushing makes a very large hole, so large in fact that it would have meant cutting into the steel plate.
I chose a 3.5 mm bushing with a 1.90mm inside diameter. Broaching out to 2.30mm, effectively removes .4 millimeters of brass with a remaining thickness of 1.2mm which should be enough. 3.00mm OD bushings were used for the 4 other pivot holes. Brass-plated movements present present fewer limitations on bushing diameter.
New third wheel bushing
The mainspring was cleaned and oiled. The movement was reassembled and put on the test stand.
Once on the test stand I noticed a wobble in the suspension leader which was rectified by tightening the suspension spring post.
If you are novice and just starting out in clock repair, time-only movements are excellent to begin with as there is only one train to work on but take extra care with movements that have steel plates.
Time-only Waterbury movement on the test stand
My suspicion about the mainspring was confirmed. 15 days later, it was still running.
After 5 years this movement should not have been as worn as it was and the issue is an oversized mainspring which puts an unnecessary load on the gears through the train. I am not about to replace the mainspring, it is just not worth it for a $40 clock, but my advice to anyone interested in clock repair is to source a mainspring that is correctly sized for the movement you are working on.
The cleaning and the installation of new bushings should nonetheless ensure years of reliable running.
7 reasons why a hobby such as clockmaking gives respite during a pandemic.
Builds self-esteem. Developing and maintaining a hobby is important because the small successes from day to day are enough to sustain oneself amid other pressures in life and it is the one solid thing to feel good about. It gives renewed energy to tackle other challenges in life.
Dial face, Scottish tall case clock C.1848
Avoid boredom. There is zero scientific evidence of this but boredom is responsible for a lot of society’s ills and destructive behaviours. Do you come home after a challenging workday to watch hours of TV when you could be doing something constructive and rewarding? If so, it is time to re-evaluate your life.
Junghans Sydney shelf clock C.1911
Enrich your perspective. There is an old adage: “The more you know, the more you grow”. Any opportunity to learn something new, to be challenged anew, is great for character-building by seeing the world through refreshed eyes. Clockmaking or any hobby helps one differentiate from others and provides key examples of overcoming adversity or tackling a difficult situation and emerging on the other side.
American Watch and Clock Collectors Museum, USA
Keeps you youthful. Establishing and maintaining a hobby is a healthy habit to form not just now but for your later years. Hobbies are excellent for brain health and help stave off cognitive decline. The older you become the more difficulty you will have struggling to fill your time with meaningful activities. Beginning a hobby early in life pays dividends in the long run much like an interest-bearing investment.
Schatz W3 bracket clock C. 1950s
Combine your hobby with other interests. Photography and traveling are two other of my interests. Blogging is another, of course. Clockmaking combines all of those interests and as a side benefit my wife, who is also my travel partner and clock locator, provides encouragement every day.
Westclox LaSalle alarm clock C. 1934
It makes one interesting. Talk about your occupation or your grandchild and before long people’s eyes begin to glaze, but mention a clock that fell off a wall during the Halifax Explosion, a clock that hung in a railway station nearby, a rare clock bought for next to nothing and ears perk up.
Junghans Crispi wall clock, C.1898
A great way to relieve stress. Hobbies provide stress relief simply because it is an oasis, a way of disconnecting temporarily and we all need a place of refuge in trying times.
Mauthe wall clock circa 1895
We are nearing the end of the pandemic and folks are returning to their former routines. If you have found a new hobby in the past year there is no doubt you have certainly acquired new skills, renewed confidence and furthered your knowledge. Don’t stop now!
Servicing the movement is complete. Next is the case.
For those unfamiliar with the HAC acronym, it stands for Hamburg American Clock Company, a well-known German company that was acquired by Junghans in the late 1920s. I have a number of German clocks including Junghans, Mauthe, Hermle, Jauch, Gufa, and Gustav Becker but this is the first HAC clock in my collection. This clock dates to somewhere between 1900 and 1908.
Here is the auction photo of the clock.
HAC mantel clock (reproduced with permission)
As you can see there is some wear as expected from a 100+-year-old clock. The dial is especially grimy.
I focused on the dial first, managing to remove most of the grime while retaining its patina. Plus I touched up the numbers and chapter ring. There were numerous scratch marks on the dial surround and I did my best to clean it up and make it more presentable but it is what it is. Check out this article for more information on cleaning the dial.
HAC clock is attractive but the dial required a lot of work
Stripping a case is always the last resort in my view. There is visible wear on the bottom corners, the lower part of the columns, and column capitals but not enough to justify removing the finish.
I cleaned the case with Murphy’s soap, applied 2 coats of shellac using 4X0 steel wool between coats followed by a coat of Minwax finishing wax.
HAC mantel clock
Better but not perfect but perfect was never my goal. Now, where to put it?
The movement has been serviced and the next step to bringing this clock back to life is cleaning a very grimy, tarnished and worn dial.
For those unfamiliar with HAC or, The Hamburg American Clock Company (Hamburg Amerikanische Uhrenfabrik), it is a well-known German company that was incorporated in 1876 as Landenburger and Lang, later with a name change to HAC in 1883 and was eventually acquired by Junghans in 1926.
Its best-known trademark is the “crossed arrows” symbol found on the movement plate and the coil gong. Unlike most HAC clocks there is no cross arrows trademark on the gong though there is one on the movement behind the pendulum rod. The name “Hamburg” was chosen at the insistence of one of its investors and “American” refers to similar American-style production methods.
I have a number of German clocks including Junghans, Mauthe, Hermle, Jauch, Gufa, and Gustav Becker but this is the first HAC clock in my collection.
HAC clock auction photo
I bought this clock online at an estate auction in February of 2021 and because of the pandemic I had it shipped to me. The only thing I had to go on were the auction photos but it is no different than taking a chance on an eBay or similar site. Once I opened the package it is what I excepted, no surprises.
While it is an attractive design it is dirty and likely has never been cleaned. There are no parts missing, a bonus, but the case and dial require attention.
The most distracting element is the dial. In short, it is a mess.
HAC dial closeup
Two options
One is to replace the dial from a donor clock but given the small amount of money put into it, the fix would have been pricey. Those I have found in my internet search are going for more than I paid for it. The second option is to clean it up and make it as presentable as possible.
Cleaning the dial
Normally I use a good water-based cleaner to remove grime from a dial but in this case, the blackish-grey tinge you see in the above photo is actually 100 years of built-up oil, grease and grime. I am sure an auto mechanic owned the clock and adjusted it before he washed his hands.
Drastic measures are called for. I knew that I would be stripping the remainder of the cream-coloured paint from the dial but as I discovered, there is so little paint left that it would not have made a difference. The numbers were also rubbed away after years of use.
HAC clock is attractive but the dial needs a lot of work
I took the dial out of the case and using Q-tips and a cleaning solution took away as much grime as possible. Some 50 Q-tips later I managed to remove most of the dirt. After rinsing with water and wiping the dial, I filled in the numbers using water-based acrylic black paint, a fine-tipped artist’s brush, and a fine-tipped .6mm permanent marker for the chapter ring.
HAC dial after cleaning and numbers touched up
The dial came out marginally better and the original patina has been somewhat retained. I am pleased with the result but that is as far as I will go.
From a distance, it is presentable and less distracting.
Eight years ago I acquired my first Arthur Pequegnat clock. In the years following, I have added to my collection and now have a total of 8. Although my collection of Pequegnat clocks is very modest by comparison to a dedicated Pequegant collector it is a good start and I would certainly like to add to that number in the future.
The Arthur Pequegnat Clock Company (1904–1941) is notable as the longest-lasting Canadian-based clock manufacturer. They made a wide variety of different styled clocks from 1904 through to 1941 from shelf and mantel clocks to wall clocks and floor models.
Nickle-plated steel or brass plates
Unfortunately, it is very difficult to date a Pequegnat clock, except for what is termed pre and post-Berlin, the location of the company’s manufacturing plant. Clocks made before 1917 were inscribed “Berlin, Canada” on the dial face. Kitchener, Ontario was known as Berlin prior to and during the first World War. It was the town of Berlin from 1854 until 1912 then the City of Berlin from 1912 until 1916.
Because the name Berlin was associated with the war against Germany the town fathers decided the name Kitchener was less offensive and the change was made midway through the First World War. Kitchener is the present seat of the Regional Municipality of Waterloo, Ontario, Canada.
Most Arthur Pequegant clock movements are stamped with the company name but there are no date marks on movements indicating when it was made. Clocks made after the First War wore the company name plus Canada under the number 6 on the dial face. For example, clocks such at the Canadian Time were made from 1904 to 1941 and are separated in age by the Berlin label consequently, my Canadian Time wall clock with the Canada label could be as old as 104 or as “new” as 80 years old.
One distinctive feature on many movements is the use of nickel plating for both brass and steel plates.
Arthur Pequegnat Company name
Many models continued in production right up to 1941. By 1941, the demands of World War II armament makers for brass, the essential ingredient in clock movements as well as the growing popularity of the electric clock, forced the Arthur Pequegnat company to cease production.
And now, beginning with the first clock acquired in 2013.
The Canadian Time
My first Pequegant, purchased in September 2013 hung in the Intercolonial Rail Station waiting room in Pictou, Nova Scotia.
Canadian Time
The seller arranged the purchase of the clock just prior to the station’s decommissioning in 1993. It is in very good condition, missing its door clasp but otherwise intact. There are a few scratches and nicks consistent with its age but nothing objectionable.
The Brandon (2nd edititon)
I found this clock in an antique shop just outside Truro, Nova Scotia in 2014.
Arthur Pequegant Brandon II
The case is in excellent condition but the movement was quite worn. Had I known more about servicing clocks at the time of purchase I would not have sent it to a clock repair specialist. It is one of two in my Pequegant collection serviced by someone other than myself. This is the Brandon II. The Brandon 1, the first edition, was made prior to 1918, and had an ornate pressed wood bezel. This one is simpler in design.
The Maple Leaf “Fan-top”
Next came my first Maple Leaf kitchen clock, known for its unique lower tablet of scattered maple leaves and a distinctive maple leaf pendulum.
Arthur Pequegnat Maple Leaf kitchen clock
This clock, bought in 2015, was also serviced by a clock professional. The case was in very poor condition. Stripping a case is an absolute last resort as far as I’m concerned but the finish on this clock was pretty bad. I could not leave it as it was.
The finish on a Pequegnat fan-top clock
To Pequegnat collectors, it is known as the fan-top.
The Simcoe
Three years later, the Simcoe followed me home. It was bought at an antique shop in Victoria, British Columbia in 2018.
Arthur Pequegnat Simcoe mantel clock
It is not particularly attractive. It is the only mantel clock in my Pequegnat collection and it is from the “Berlin” period.
The Bedford
2018 was a good year because I acquired 4 Pequegnat clocks. This was number two of that year.
Bedford shelf clock
This clock was gifted to me by a reader. He asked if I wanted the clock but I had to pick it up in Quebec which was on our way to a summer cottage in central Canada. The movement was in very good condition but the case was damaged having taken a plunge off a high shelf.
The movement was serviced without issue but the case required extensive intervention.
The third purchase that year and the fifth in my collection is the Maple Leaf Pointed Top
The Maple Leaf “Pointed Top”
There are 4 Maple Leaf clocks made by Pequegnat. Any version of the Maple Leaf is sought after by Canadian collectors but this one has distinctive pointed side columns, hence the nickname.
Arthur Pequegnat Maple Leaf Pointed Top
Although termed a kitchen clock it could easily have been placed in a living room or parlour.
The Moncton
The last 2018 acquisition was a clock that I had in the back of my mind for quite some time and I was waiting for the right price. This is an excellent copy that is very presentable and looks great on our kitchen wall.
Arthur Pequegnat Moncton
It is a post-Berlin double spring time-only 15-day clock. Many were used in rail stations despite the fact that they were spring-driven. Weight-driven clocks were preferred for their accuracy but the Moncton was up to the task as a timekeeper.
And the last.
The Canuck
This is the only true Pequegant “gingerbread” clock in my view.
Canuck kitchen clock
The case was refreshed and the dial was redone. The movement was also serviced without issue.
Cleaned up more presentable
These are all keepers. Most Pequegants have kept their value over the years and in Canada, they are regarded as quality clocks for the masses. They were well built, well-designed movements with a distinctive Canadian charm as many were named after cities in Canada.
Tick-Talk Tuesday is about the letters and comments I have received from you, the reader, concerning your clock, issues you might have had, challenges you face, a clock you would like me to profile, my advice on your particular clock concern or a general clock question. For those comments and questions that stump even me, I consult within my clock circles for the best possible answer
Photo attached to KBs email
KB writes, “Hi Ron, I have been following your blog with interest, I have a a interesting collection of clocks, longcase, carriage and mantle. I am now in the process of restoring them. I need some help with bushing, can you please tell me how you do this. Many Thanks”
My reply
“You can hand bush, use a drill press or a bushing machine such as the Bergeon Bushing machine as demonstrated in this video. The bushing work is at the 6:40 point of the video if you want to skip ahead.
I want to share my experiences dealing with clock suppliers and let me begin by saying that my experiences have been largely positive.
I have been repairing and restoring clocks for the past 10 years and since I live in Canada I generally deal with one mechanical clock parts supplier out of Toronto, Ontario, Perrin. They are excellent for most of my needs, but they do not have everything and from time to time I must locate special or unique parts through other suppliers such as Merritts, Timesavers, and Ronell from the USA and Meadows and Passmorein England.
For example, I recently completed the restoration of an Ingraham Grecian shelf clock, circa 1871, and it required a new set of hands. The hour hand that came with the clock was too short and the minute hand was the incorrect style. My goal in this case is a clock that is as authentic looking as possible and incorrect hands always takes away from a clocks appearance.
My Canadian supplier did not have the correct hands and eventually my search brought me to an out-of-country supplier, Timesavers.
Ingraham Grecian Harris and Sons auction photo
Ingraham Grecian with correct sized moon hands
Had I ordered just a set of hands the shipping cost would have been substantial.
In order to justify the purchase I added additional parts; 2 smoothing broaches, a Seth Thomas #2maintaining spring, brass weight cable, a riffler set, and a bob wire set. The total came to $36US. The shipping and processing fee is $24US. Factoring in the rate of exchange the order cost me $82CDN.
If my Canadian supplier had everything I needed the cost would have been $20 less. It was not a significant difference in this case but it was worth it to find the correct hands.
What are the costs?
The sourcing of parts from various suppliers especially outside Canada can be expensive when administrative costs, shipping fees, exchange rates and import duty are included.
Some suppliers, however, require a minimum order. Others apply a credit card fee for international transactions, still others apply a processing fee and occasionally there is import duty. In almost every case the cost is higher and in some cases, it may not be worth it.
There are a number of choices for shipping but the cheapest method is not always “cheap”. Ground shipping in Canada is fairly inexpensive. Many out-of-country suppliers ship by air and the cost can be significantly higher.
That little $2.99 part can easily cost $20 or more after all costs.
Parts Availability
Seth Thomas Regulator #2
Not every supplier is going to have what you want. There are similarities from one supplier to another but there are also differences. For example, one is likely to find brass carriage clock feet from an English supplier because bracket and carriage clocks are much more common in that part of the world. English suppliers will also carry more tall case, and carriage clock parts and obviously, American suppliers will have many parts for clocks made in the USA.
The upside is that by knowing the various suppliers and their inventories I am able to satisfy most of my clock parts needs. If I only need one part I will always add additional items to justify the shipping and other costs.
My strategy for sourcing parts
If I were in the clock business and required one part, I would pass all costs on to the customer. I do not run a repair service and can afford to put a project aside if it needs parts and wait till I can justify an order.
I build a list of parts using an Excel spreadsheet, and when I feel there is enough to justify an order I pull the trigger. I can afford to wait.
As far as prices are concerned, companies such as Timesavers in the US have locked in their prices till 2022 while prices for some items at Perrin, a Canadian supplier, have increased marginally in the past year. Still, I buy Canadian when I can.
When ordering, if there is an offer of a free parts catalogue I always ask for one.
I also take advantage of every opportunity when I find pendulums, clock keys and other sundry items in flea markets and antique shops and snap them up, IF the price is less than I would buy from a supplier.
Clock parts are not cheap. If you are looking at clockmaking as a hobby factor in the cost of basic and more advanced tools but know that consumables can cost much more in the long run.
From my experience, most suppliers are excellent to deal with are and the service is speedy and professional. Just be mindful of all those other fees. It can really add up!
Clock collecting from a beginner’s perspective. That was the subject of my first blog post six years ago. Since then I have seen a lot of excellent and not-so-good blogs come and go but I wanted to give it my best shot and after 6 years, well, I am still here.
I started with a free WordPress plan, moved to a personal plan and then, this year, to a Premium plan. I now permit advertising on my site but my only goal is to recoup costs for server space and domain name. Anything extra is gravy.
In the early days I would stop blogging in the summer and resume in the fall. That did not work so well as my viewership fell off and I had to rebuild after the holidays. Now I schedule all my articles in advance. In fact, I typically have about 15-18 articles “in the can” at any given time. Having an inventory of articles means there is no need to scramble with something new every 3-4 days, my typical interval between articles. Some of you bloggers must know how hard it is to put words together when inspiration is lacking.
I am not sure what I was expecting 6 years ago but now have a dedicated following, receive many interesting letters each week, have met people through my blog and it seems people appreciate my content. This is reflected in statistics which are the lifeblood of any blog and it’s those daily figures that keep a blogger motivated. For instance, I have more views in a typical day than I had in the first 3 months of my blog.
Not once do I claim to be a professional horologist but after 10+ years in clock repair as a hobbyist I think I know something by now.
Welcome to my first blog post written May 15, 2015 which I will present word for word.
OK, so it’s a Chinese clock but it works
I regard myself as a clock collector and tinkerer. I am not a trained horologist nor do I have a unique talent for clock repair or even getting a simple clock back to working order, but I find the world of horology to be quite fascinating.
It is a relatively new hobby for me which began with the purchase of a Daniel Dakota time and strike wall clock. Why start with a Chinese-made clock which most would consider inferior to almost any other clock in the world. It was cheap, it piqued my interest in collecting and repair and it was something to practice on. I then moved on to a Ridgeway grandfather clock and to my current collection of Mauthe, Seth Thomas, Hermle, Forestville, Sessions, Smiths Enfield, Muller and Pequegnat clocks.
Arthur Pequegnat kitchen clock, known as the “Fan-top”
My blog will profile clocks in my collection both vintage and antique as well as describe my attempts at repair. Along the way I will seek advice from you, the reader, from clock forum sites and whatever information I can find online.
Seth Thomas Adamantine mantel clock
Clock collecting is a great conversation starter and it allows me to combine my other passions, photography and traveling (and now, writing). Locating good clocks means traveling around the province of Nova Scotia and Canada, meeting interesting people along the way and is some cases getting that one-of-a-kind deal.
Most photos on this site are my own. Photos from other sources will be given full credit. I will try to capture the beauty of these old mechanical wonders and anything about their provenance will included as well.
Forestville Westminster chime mantel clock
Stay tuned. It is all a learning experience and as I bravely go further into the hobby I hope to share my frustrations and my successes.
As Winston Churchill once said, “Success is walking from failure to failure with no loss of enthusiasm”.
I have stayed true to form since then and continue to publish 7 to 9 articles per month. Since then I have acquired dozens of antique and vintage clocks from all over Canada and probably have upwards of 80 clocks in my collection at this point. I have also said goodbye to an additional 20 clocks through local sales and as gifts. It remains a hobby that I thoroughly enjoy although occasionally I have done some paid and pro bono work.
If you have stayed with me since the beginning, thank you, but if you are new to my blog or following for the first time, welcome!
This clock is an antique store find not too far from where I live. It was high on a shelf and the price was not visible. I asked the shopkeeper to take it down so that I could check the price ($40) and verify that it had a mechanical movement.
Seth Thomas cabinet clock?
I opened the back panel, quickly glanced at the movement and the trademark stamp appeared to be Ansonia. I had worked on an Ansonia Syria shelf clock in the past year and it looked quite similar but it was an odd looking movement for an Ansonia. Ansonia movements generally have an arched plate, this one had a hump. No matter, I bought it.
Ansonia Syria cabinet clock
While at home I was able to examine the clock more closely.
What did I buy?
I discovered that the movement is made by the Seth Thomas Clock Co. not by Ansonia. The movement was made for about 12 years and was available from 1890 to 1902. The style of the case is also from the same period.
An exhaustive search of Seth Thomas clocks on the internet using keywords such as, shelf, parlour (parlor), cabinet, carved oak and mantel produced nothing. I then navigated to a well-known Seth Thomas database site, poured through hundreds of listings and again, zilch.
I began to realize that the case might not have been made by Seth Thomas, after all.
However, I was determined to find the maker. I searched for clocks made by other companies, starting with E.N Welch, Ansonia (because it is similar in style to the Syria), Gilbert, Sessions and finally Waterbury. When I used the term “Waterbury cabinet clock” I found it on an auction site. So, now I have a case made by a different maker than the movement.
What is a marriage?
Among clock circles it is generally accepted that if a clock has significant parts from another source, particularly the movement and put into a period correct case from a different maker, it is considered a marriage. If it has parts sourced from a number of other clocks it is a Frankenstein or Frankenclock. While this clock is not quite a Frankenclock it is certainly a marriage.
Waterbury Wren case
I am actually disappointed that this clock is a marriage
The case is a Waterbury model called the “Wren”. I found three Wren models, two with paper dials and one with the identical dial pan as my clock. It may well be that this dial pan is original to the case.
The concave brass bezel and glass are certainly more recent. When I first looked at the clock I knew that the brass bezel and glass were incorrect but that did not stop me from buying the clock. The original bezel would have been a piecrust design with flat glass. This glass bezel is from a 1930s vintage clock.
The back access door is made of plywood, a recent addition and, of course, there is no label. The original panel would have been made of solid wood and screwed to the sides of the case with a circular tin access port. The label would have been located on the outside under the port door or underneath the base,
Does the movement run?
The movement is complete with pendulum bob and ST key. It was sold as a non-running clock, but will the clock run?
While the movement was still in its case I applied mainspring oil to the tight mainspring, allowing a few minutes for penetration. I then removed the verge so that the time train would run freely, using my finger as a brake on the escape wheel. It was sluggish at first but eventually the sticky time side mainspring made several soft clunking sounds as it ran down.
You can see the very tight time-side mainspring in the next photo. Grime and built-up dirty oil over the years will seize a mainspring.
Once the mainspring was partially let down I reattached the verge and the clock would stop after a minute or so. There was definitely power going to the escape wheel but something else was amiss. It would skip a tooth or two with every rotation which told me that the pallets were too far from the escape wheel. There is an adjustment screw on an arm which allows the pallets to be moved closer (or further) to the escape wheel. I eventually found the correct distance and the clock began to run normally. At the same time I opened the crutch loop wider to allow more impulse.
This is certainly no substitute for an overhaul but a good diagnostic tool.
Meanwhile, the strike side ran perfectly.
The movement is running and keeping good time but it needs a cleaning and several wear issues addressed.
Seth Thomas 8-day time and strike movement
Next steps?
I am actually disappointed it is a marriage. Buying a clock is always a risk and if I had paid many times more for this clock I would have asked for my money back.
I am not sure what I am going to do with it but I am inclined to service it and perhaps put it on the market. If I sold it I would certainly disclose the fact that it has a period correct replacement movement from another maker.
Nevertheless, it would make an attractive clock once the case is cleaned, the movement is properly serviced and has the correct glass and bezel.
Canadian clock collectors familiar with companies such as Arthur Pequegnat, the Canada Clock Company, the Hamilton Clock Company, Forestville, and Fleet seldom consider the Snider Clock company clocks for their collections yet for a quarter of a century this home-grown Canadian company made mantel and wall clocks designed and manufactured in Toronto, Ontario.
Starburst clock in a boutique hotel, Quebec City
Harry Snider began making clocks in 1950 under the name Snider Clock Corporation. The name then changed to the Snider Clock Manufacturing Company Limited in 1957. Throughout its history it continued as a family venture until the last clock was made in 1976.
A master clock surrounded by Snider clocks, Canadian Clock Museum, Deep River Canada
Some say they only made fashion and novelty clocks and to some extent that is true. The Snider Clock company’s response to the trends and fashions encapsulated a healthy design philosophy that kept pace with the times. Innovation, quirkiness with fanciful designs are the hallmarks of their approach to clock manufacture.
Former Snider Clock Company location in Toronto as it appeared in 2007
The company began by making mantel clocks with mechanical versions supplied by Ingraham, and later, mantel clocks with electric motors imported unassembled from the Lanshire company in Chicago. In 1960 Snider shifted focus to wall clocks which were in great demand at the time, a demand likely brought on by the Sputnik satellite, the interest in space adventure and the dawn of the “Atomic age”. Models with starburst and molecular patterns attracted new buyers.
Most models were corded electric clocks but in order to do away with the cord Snider offered an upgrade to electromechanical models with battery movements. The advantage of a battery movement was the flexibly in placement anywhere in the home.
The longest running style of clock was the starburst clock. When I think of a Snider clock the first image that comes to mind is an electric kitchen wall clock in a starburst or sunburst pattern. These were very popular and Snider sold thousands.
Telephone clock
However, Snider made unusual and fanciful lamp clocks, telephone clocks, in china, metal cast, brass-plated metal and many colours such as in brown, pink, turquoise and black.
Snider Novelty clocks, Canadian Clock Museum
In the peak years, the company made 50,000 clocks, had 20 employees, and used mainly Canadian components. Throughout its history, it strove to constantly adjust to a constantly changing market.
In 1976 when Caravelle clocks (a subsidiary of Bulova) arranged licensing agreements with retailers in Canada, Snider could not compete and ended its business after 26 profitable years. A sad end to a company ultimately pushed aside by an American competitor.
This E. Ingraham & Co. clock is a garden variety parlour clock. There is nothing special about it but among parlour clocks, it has nice lines and reflects a more conservative approach to clock designs of the late 19th century. It is an 8-day time and strike clock purchased from a local antique store in the spring of 2019. I have recently serviced a number of clocks in preparation for sale and I also considered selling this one. While I am not in the business of selling clocks I will let go of the odd one to keep my collection manageable. My wife feels that it is a keeper though and I agree.
This was a running clock before I took it apart and my goal is to give it a good cleaning and address wear issues
Stamped in the middle of the front plate is “E Ingraham Co patent date Oct 8, 78 Nov 11, 79, Bristol Conn.” On the inside floor below the pendulum, it is stamped “Manufactured by the E. Ingraham & Co, Bristol Conn”. It was not a common practice to stamp the inside floor but it is an interesting feature.
E Ingraham parlour clock with Swigart dial
Tran Duy Ly’s book on Ingraham clocks shows this model, the Mystic, from the 1897 catalogue. The clock sold new for $6.50. Although found in the 1897 catalogue it might have been made some years earlier. Two numbers are neatly etched into the lower right-hand side of the front plate and they are H25,915 and H27,475. They look like service dates, Sept 1915 and April 1975.
There is a stylized “S” logo on the dial face. Some might mistakenly take it for a Sessions clock. The dial is a replacement made by E&J Swigart, a supplier of replacement dials along with other clock and watch supplies. Swigart went out of business in October of 1992. 1972 was the last year they made reproduction clock dials and this appears to roughly coincide with the 1975 service date.
Assessment of the movement
I have worked on a number of Ingraham movements, some with helper springs and some without. It looks to me that helper springs were added, which is not a bad thing and they will stay on the movement. Installing helper springs to ensure levers drop as they should is not an uncommon practice.
Normally these old movements are in varying degrees of wear and quite often there are punch marks around almost every pivot hole plus they are very dirty. This movement has had 13 bushings installed and is surprisingly clean for its age.
This was a running clock before I took it apart and my goal is to give it a good cleaning and address wear issues along the way. It might require some intervention but my first impression is that it looks very good.
Ingraham Mystic
I found a bent second wheel pivot on the strike side. Before blaming a previous repair it is possible that I was the culprit. Both mainsprings were clamped to restrain their power but when I removed the top plate a wheel sprung out from the strike side. Evidently, the strike side mainspring still had residual power remaining and might have bent the pivot. It was easily straightened.
The main and second wheels on both sides are inscribed for location, so, that is helpful. The strike side mainspring arbour hook has been repaired although the pin is loose and had to be secured. It also appears both mainsprings are replacements. The warning wheel lantern pinion shroud has also been repaired. The clutch on the motion works looks like a repair but I have seen at least one other Ingraham like it, so, I’m not sure.
Ingraham Mystic, warning wheel with additional punch marksIngraham Mystic, motion works clutch
This clock has had a lot of attention and has led an easy life. The repairs are neat and tidy and appear professionally done.
But there is some wear. The clock requires bushings on both the time side and the strike side. One on the time side and 3 on the strike side, one new, and 3 replacement bushings.
Reassembly and testing
The third wheel on the strike side is a combined locking and pin wheel with 2 locking pins and 2 hammer pins. There is no cam on this arbor, unlike many other American movements. The spaces between the pins allow for the drop lever to descend.
The count wheel is advanced by two protruding pins on the third wheel lantern shroud. It is necessary to ensure that the count wheel is firmly in place, not loose but not too tight, so the third wheel pins can advance the count. The warning wheel is set about half a revolution to set up the strike. During reassembly one of the two lock pins is placed on the locking lever, the end of which has a hook. This is to permit the count lever to go into one of the deep slots.
Since I have worked on a couple of Ingraham movements in the last month there was no need to separate the plates to make additional adjustments.
Unlike earlier Ingraham movements that have no passing strike on the half-hour, this has one.
It is on the test stand and I will let it run for a cycle or two before returning it to its case.
Ingraham Mystic on the test stand, beat amplifier attached
It’s really nice to work on a clock that has been so obviously well cared for. It will look great and run well though the only item that detracts from the clock is the Swigart replacement dial.
The arrangement of the gears should be familiar to anyone working on German clocks made in the first quarter of the twentieth century
Bought on an online estate auction site earlier this year, servicing the movement is the subject of this post. Once the movement is serviced, the next step is to address dirt and grime on the case and see what I can do to improve the look of the dial although I am not very hopeful that I can do much to improve it.
For those unfamiliar with the HAC acronym, it stands for Hamburg American Clock Company, a well known German company acquired by Junghans in the late 1920s. It is otherwise known as Hamburg Amerikanische Uhrenfabrik or HAU. Kind of a strange name for a German clock company but that is how the original investors wanted it named.
I have a number of German clocks including familiar makers such as Junghans, Mauthe, Hermle, Jauch, Gufa, and Gustav Becker but this is the first HAC clock in my collection.
HAC clock circa 1900-1910
Assessment of the movement
It is a typical 14-day German time and count-wheel strike circa 1900 to 1910. It is a robust and almost industrial looking movement and perhaps made early in this series of movements. It could be the type #21 although I can find nothing to confirm it.
The arrangement of the gears should be familiar to anyone working on German clocks made in the first quarter of the twentieth century. This movement has slightly thicker plates, no cutouts, and no extraneous holes and looks sturdy.
HAC clock movement, dirty and very tarnished
It has been worked on in the past, the strike side mainspring having been replaced at some point in the clock’s life. The time side has the HAC cross arrows stamped on the mainspring and appears to be original.
HAC clock movement, no cutouts
It doesn’t look as though there were issues at the time when the mainspring was replaced, no punch marks around the pivot holes or new bushings, for example, but there are wear issues now and that is to be expected in a 100+ year old clock movement.
In total the movement required 9 bushings, 6 on the strike side and 3 on the time side; 4 on the backplate, and 5 on the front plate. A couple of pivot holes are questionable and exhibit some wear and out of an abundance of caution I bushed them and why not while I have the movement apart. As expected there is more wear on the lower parts of the trains.
The bushing work went as expected. Some of the pivots are quite small and required 2.50mm OD bushings which I don’t often use but have plenty of them in my supply.
Ultrasonic cleaning did not do much to brighten up the brass plates, but to me aesthetics is unimportant. My goal, as always, is simply to have a properly serviced movement that runs well.
Assembly and testing
The movement was assembled and oiled. Both the strike and the time side are running well. There were no particular problems setting up the strike side other than a couple of attempts setting up warning before I got it right.
HAC movement on the test stand
It continued to run well during the next couple of weeks.
It is a 14-day movement but I find with these German movements that winding them once per week ensures more accurate timekeeping.
Antique and Vintage Mechanical Clocks
You must be logged in to post a comment.
