The Pequegnat Jewel and the Simcoe – similar yet subtly different

The newest addition to my collection of Pequegant clocks is the Jewel. That marks a total of nine Pequegnat clocks in my modest collection. I was not actively seeking a new clock. In fact, I haven’t purchased one in months, and mantel clocks weren’t even on my radar.

_{Arthur Pequegnat Simcoe, note the legs and side details}

I bought the Simcoe (above) in 2018 from a shop in Victoria, British Columbia (Canada) and I think, at the time, I paid close to $200 for it. I located the Jewel in an antique shop about 20 minutes from where I live. I recognized it almost instantly, even though it was placed on a shelf nearly out of my reach.

The Jewel’s price was significantly lower so, why pass it up?

_{Was the seller confused about the maker?}

The two clocks boast strikingly similar case designs. In fact, the dimensions of the quarter-sawn oak case are identical, although the Simcoe model is slightly taller due to its corner feet and wider due to the addition of lion-head handles on each side. Both contain the same 8-day time and strike movement.

Pequegnat Jewel time and strike mantel clock

Made in Canada before 1916, this clock has an 8-day, spring-driven time and strike movement with signature Pequegnat nickel-plated plates. Initially, I thought there might be brass bushing inserts on steel plates. However, upon passing a magnet over the plates, I discovered that the plating was not on steel but on brass. Plating over brass may not be the most practical solution, but aesthetically, it offers a pleasing appearance.

Although the movement bears the stamp “The Arthur Pequenat Clock Co., Berlin, Canada” there is no maker’s name typically found on the lower section of the dial face, a peculiarity I’ll delve into shortly.

Pequegnat Simcoe dial face — _{Simcoe dial with cracked and lifting paint}

Both “Berlin” Simcoe and Jewel models feature pie-crust dials, setting them apart from later clocks with plain brass bezels.

Why are they called “Berlin” clocks? In 1916, the town of Berlin, Ontario faced considerable backlash due to the ongoing war in Europe, with its name being associated with the enemy of the time. These wartime tensions prompted the town to undergo a name change to Kitchener, Ontario. While Pequegant clocks lack a specific date stamp, the town’s name change serves as a useful reference point for dating these clocks. The company had a relatively short lifespan, being founded in 1903 and ceasing production in 1941.

Showing the time and strike movement of the Pequegnat Jewel — _{Jewel movement}

The case is in excellent condition but I was drawn to the dial immediately. Something is certainly amiss. At first, I suspected the dial had been replaced, but upon closer examination, I realized that a previous owner had scraped off the paint from the dial, leaving the numbers intact. It’s not unexpected. With time, the paint on these dials tends to degrade, and it’s likely that it had deteriorated to such an extent that the decision was made to remove it altogether.

Should I overlook this issue and simply accept it as is, or address it by repainting the dial?

Paint scraped from the Jewel dial — _{Paint scraped from the dial}

The most interesting aspect of this clock is the price. Although antique clock prices have been depressed in the last several years, Canadian-made Pequegnat clocks seem to hold their value quite well. A quick perusal of auction sites reveals that realized prices for the Jewel hover between $100 and $250 with the Berlin-made clocks commanding a higher price.

While the movement, unfortunately, does not run, based on my experience with other Pequegnat clocks in my collection, I suspect it may be gummed up with dirt and could potentially require a bushing or two to have it run as it should.

A worthwhile acquisition at an excellent price point.

April 23, 2024

The Steeple Clock – function combines with design

A steeple clock is a type of clock designed to resemble a miniature church steeple or spire. This style of clock is often characterized by its tall and narrow structure.

These clocks gained popularity in the mid-19th century and were often produced in various styles. The design was influenced by the Gothic Revival architecture that was prevalent during that period.

Steeple clocks are relatively common in North America as thousands were produced in America particularly but rare in other parts of the world.

New haven Gothic Steeple clock — _{New Haven Gothic Steeple clock}

In my collection, I own three steeple clocks – the first, crafted by the American manufacturer Elisha Manross, the second by the Hamilton Clock Company of Hamilton, Ontario, and the third by The New Haven Clock Company of America, made for export and sold by Thomas Spike Jewelers in Halifax, Nova Scotia in the 1880s.

All three share a commonality with their time and strike 30-hour spring-driven movements.

The Elisha Manross steeple clock stands out with its distinctive use of tempered brass mainsprings, marking a period between 1836 and 1847 when this material was the motive force for spring-driven clocks. It represents a technological glimpse into an important era in American clockmaking.

However, it is the steeple clock from the Hamilton Clock Company that holds a special place in my collection. Being a Canadian collector, the clock not only adds historical charm to my collection but also carries significance because it is Canadian-made.

Crafted in Hamilton, Ontario, it embodies a piece of Canadian horological heritage, making it more than just a clock but a connection to the craftsmanship and legacy of clockmaking in Canada.

_{Hamilton Clock Co Gothic steeple clock}

The Hamilton Gothic steeple clock stands out because of a religious inscription, “Cling to the Cross,” delicately etched onto the lower glass tablet. It is a rare clock from the Hamilton Clock Co., which manufactured a variety of clocks of every style over a very short period.

The historical weight of this 30-hour steeple clock is underscored in Jim Connell’s description in a video he produced several years ago. Connell, a figure renowned in Canadian clock circles, whose acknowledgment of the clock’s rarity adds an extra layer of importance to this find. Fun fact, Jim Connell invented salt and vinegar potato chips.

This clock carries whispers of a bygone era, a testament to the Hamilton Clock Co. which, between 1876 and 1880, made a valiant though short-lived attempt to compete with the growing number of common clocks coming from the USA.

Steeple clock discussion

The term “Gothic steeple clock” specifically refers to clocks that incorporate Gothic design elements, such as pointed arches, into their structure.

An unusual "ribbed" style steeple clock — _{An unusual “ribbed” style steeple clock}

Steeple clocks can vary in features, including different types of movements.

_{A trio of steeple clocks with an 8-day fusee clock in the middle}

The vast majority were relatively simple designs that were spring-driven but there are some very rare examples of steeple clocks that are weight-driven and ones that incorporate fusee movements.

R. Blakeslee, Jr. in or around 1850 made a 30-hour weight-driven clock with a lyre movement (not pictured). His clock also featured a compound pulley configuration on the time side, the time side weight being heavier than the strike side.

Even more unusual are double-steeple clocks, a noteworthy example being a Birge and Fuller 8-day fusee-powered brass movement clock (not pictured) made in the mid-1840s.

During the same period, Elisha Manross made a double steeple shelf clock that had an 8-day time and strike strap brass fusee movement with a 12″ pendulum (not pictured). It features the original stenciled and painted tablets by William B. Fenn of Plymouth. William Fenn was one of the more prolific tablet makers of the mid-19th century.

By comparison to a conventional steeple clock that stands at about 20 inches, double steeples are over 6 inches taller.

Jerome & Co. New Haven, Conn, 1850 steeple with portrait of Andrew Jackson — _{Jerome & Co. New Haven, Conn, 1850 steeple with the portrait of Andrew Jackson}

Jerome & Co. of Chauncey Jerome fame also produced a double steeple in 1850. The one pictured above features a portrait of the seventh President of the USA, Andrew Jackson.

_{Gallery-style gothic clock, a variation of a steeple theme}

Steeple clocks are appreciated by collectors for their historical charm and unique aesthetic, reflecting the craftsmanship and design of the era in which they were produced. They also stand as tangible expressions of the artistry and cultural influences of their respective historical periods.

February 23, 2024

Regulator #1 by Arthur Pequegnat

One clock that holds a special meaning and one that I would like to add to my collection someday is the Arthur Pequegnat Regulator #1, a single-weight eight-day clock. This clock is truly a rare find, though the prices I’ve encountered thus far are a bit steep for my budget.

The Arthur Pequegnat Story

The Arthur Pequegnat clock company was a formidable contender to American wall clock manufacturers. While their wall clocks often mirrored American models, some of their designs boasted a unique touch. The company favoured the heartwood of quarter-sawn white oak for their cases, showcasing the stunning visual appeal of this choice of wood.

The story of the Arthur Pequegnat clock company is one marked by distinction. Born in Switzerland in 1851, watchmaker Arthur Pequegnat immigrated to Berlin, Ontario, Canada, in 1874 with a substantial entourage of 18 family members. Initially establishing himself as a jeweler and watch repairman in the late 1870s, Arthur and his brother Paul operated a successful shop in Berlin, Ontario, by the mid-1880s. After a decade, the brothers pursued independent ventures, each managing prosperous jewelry shops in Southern Ontario.

In 1897, Arthur expanded his Berlin Jewelry shop to include bicycle manufacturing. However, as the demand for bicycles waned by 1904, he shifted focus back to the clock industry, manufacturing his clock movements at his Berlin Bicycle Manufacturing plant. Initially, wooden clock cases were sourced from local furniture makers, but over time, Arthur began crafting his own cases.

Despite Arthur’s passing in 1927, the company, guided by family members, persevered until 1941. The scarcity of brass during the war effort led to the company’s closure. The factory, where these exceptional timepieces were crafted, never produced another clock and was eventually demolished in 1964. Today, Kitchener pays tribute to this great clock manufacturer with a commemorative plaque.

The renaming of Berlin to Kitchener in 1916, amid World War I anti-German sentiments, serves as a helpful dating marker for Pequegnat clocks. Movements or dials marked “Berlin” indicate a clock dating to 1916 or earlier, while those marked “Kitchener” are from 1916 or later. Due to the long production life of many clocks, precise dating of Arthur Pequegnat clocks remains challenging.

For a fascinating journey into the world of Arthur Pequegnat clocks, The Canadian Clock Museum stands as a treasury, boasting the most extensive museum collection of Arthur Pequegnat clocks in Canada. Additionally, the Macdonald Museum in Middleton, Nova Scotia, offers a modest yet noteworthy collection of Pequegnat clocks—a worthwhile stop for those journeying through the Canadian province of Nova Scotia.

The Regulator #1

The Regulator #1 is frequently likened to the Seth Thomas Regulator #2. While the Seth Thomas counterpart found widespread use in offices and rail stations across America, the Arthur Pequegnat Regulator #1, though less prolific, met the demands of many businesses in Canada.

_{The dial removed showing the movement}

Although sought after by collectors the Regulator #1 has interesting technical quirks according to Canadian clockmaker John Plewes, author of Repariring & Restoring Pendulum Clocks. Plewes cites three design issues with the clock. Two are minor quibbles but the third involves the weight. Despite its similarity to the Seth Thomas Regulator #2, it requires a heavier weight (1/2 lb more) to drive it reliably. A lighter weight such as the one found on the ST#2 causes the clock to stop after a short period particularly when the minute hand is rising. The hands are simply too heavy for the clock as they influence the force applied to the train.

Plewes, therefore, takes issue with Arthur Pequegnat’s claim that the #1 is the “finest office clock made”.

Regardless, the clock is highly sought after among Canadian collectors, and commands a premium, often doubling the price of similarly styled clocks from well-known American counterparts such as the Seth Thomas Regulator #2.

Ah, some day!

December 29, 2023

Honouring History, One Tick at a Time – the Halifax Explosion Dec 6, 1917

In the heart of North End Halifax, on December 6, 1917, a Junghans Crispi clock fell off a wall in a house on Princess Court. Unbeknownst to it, this simple clock would become a silent witness to one of the worst man-made disasters in Canadian history – the Halifax Explosion.

As the Belgian relief ship Imo collided with the French munitions vessel Mont-Blanc, a catastrophic event unfolded in Halifax’s harbour. The explosion at 9:04:35 a.m. reshaped the landscape, claiming 2,000 lives with 9,000 injured, and left an indelible mark on Halifax’s history.

_{Since some case parts were missing, a catalog image of the clock served as a helpful reference}

Fast forward to 2017, a century later, and the remnants of that clock found their way into my hands. The following journey is about a box of clock parts, carefully preserved by a family for generations, passing through to a new owner to be revived and displayed as a connection to history.

Very dirty movement — _{The movement was very dirty but intact}

The task of reviving the clock, and turning it into a connection to history is a process that took over two months.

The restoration unfolded step by step. The clock parts were carefully cleaned, new parts were fashioned, and the correct materials were found to restore the Junghans Crispi wall clock to renewed glory. The hands, frozen since that fateful day, started moving again – a symbol of human resilience.

The restored Junghans Crispi wall clock was finally unveiled in late 2017 and has been ticking away and gracing the wall of our dining room ever since then. Its polished wooden frame, bold brass accents, and rhythmic ticking resonated with the shared history of a city and a clock that refused to succumb to the ravages of time.

As we mark the 107th anniversary of the Halifax Explosion, my Junghans Crispi wall clock stands as a symbol of resilience, remembrance, and the power of restoration.

In the quiet corners of North End Halifax, it tells a story that transcends time – a tale of survival, renewal, and the enduring spirit of a community that rebuilt itself from that terrible moment.

December 8, 2023

Three arguments for eliminating Daylight Savings Time

Here are three commonly cited reasons for eliminating the cursed Daylight Savings Time convention:

One of the main arguments against daylight saving time is its impact on human health. The abrupt shift in the clock can disrupt people’s sleep patterns, leading to sleep deprivation and increased stress. Studies have shown a rise in heart attacks, strokes, and even car accidents in the days following the time change. By eliminating DST, people would maintain a more consistent sleep schedule, promoting better overall health and well-being.

_{A made-in-Canada Pequegnat clock from the 1920s}

Critics argue that the practice of changing clocks twice a year imposes economic costs on businesses and individuals. The process of adjusting various devices, systems, and schedules can be time-consuming and costly. Moreover, the disrupted sleep patterns of employees can lead to decreased productivity in the workplace. By eliminating DST, businesses would avoid these costs and potentially see a boost in productivity due to a more rested workforce.

One of the original reasons for implementing daylight saving time was to conserve energy by making better use of natural daylight during the longer days of summer. However, with advancements in technology and changes in energy consumption patterns, the energy-saving argument is now considered outdated. Modern studies have shown that the energy savings from DST are marginal, if any, and in some cases, it might even lead to increased energy usage due to higher air conditioning demands on hot evenings. Therefore, proponents of eliminating DST argue that the energy conservation rationale no longer holds, making it unnecessary to continue the practice.

These arguments, among others, have fueled ongoing debates about the relevance and effectiveness of daylight saving time, leading to discussions and policy changes in various regions.

But not in Nova Scotia, Canada. Prepare to set your clocks backward on November 5th at 2:am.

November 3, 2023

Cultivating a Clock and Watch Community in Canada’s Maritime Region

After attending the 2019 NAWCC (National Association of Watch and Clock Collectors) convention and participating in chapter meetings in Ottawa, Ontario, I’ve often wondered why there isn’t any NAWCC representation in the Maritime provinces of Canada – Nova Scotia, New Brunswick, and Prince Edward Island. Surprisingly, there isn’t even an informal clock and watch club in these regions, affiliated or not with NAWCC.

The nearest NAWCC chapter is in Montreal, Canada, while Ontario alone boasts three active chapters. It’s surprising that there hasn’t been an active NAWCC chapter in the Maritime provinces.

I firmly believe that there are numerous clock enthusiasts (horologists) in my area of Nova Scotia, New Brunswick, and PEI (Canada) who would love to come together to share their passion, experiences, and expertise.

To clock lovers reading this blog worldwide who are interested in connecting with like-minded individuals, I encourage you to seek out persons in your local communities. But, if you reside in the Maritime provinces of Canada – Nova Scotia, New Brunswick, and Prince Edward Island – I invite you to connect with me directly at ronjoiner@antiquevintageclock.com if you’re interested in discussing clocks and watches, sharing experiences, discussing repair techniques, or simply showcasing your collection.

_{Photo by RDNE Stock project on Pexels.com}

An effort was made approximately three years ago to initiate a club; however, the ongoing pandemic prevented in-person meetings. The timing of the club’s launch might not have been ideal, and external circumstances such as geographical challenges might have made it difficult to meet. If the club had been established in Halifax, the most populous city in my home province of Nova Scotia, several challenges would have been mitigated.

Building a community of like-minded individuals can be challenging, especially if there are no existing networks or platforms to connect clock enthusiasts in the region.

Let’s make another attempt to come together! If our numbers grow and there’s enough interest, we can establish a club. Reach out, join the conversation, and let the allure of clocks and watches bring us all together.

And who knows, in the future, we might even explore the possibility of obtaining charter membership with NAWCC.

October 13, 2023

Tick Talk Tuesday #51 – My Arthur Pequegnat clock

^{Tick-Talk Tuesday is dedicated to addressing readers’ letters and comments related to clock issues, challenges, and recommendations for specific clocks. In cases where the comments and questions are particularly challenging, I seek advice from my fellow clock enthusiasts to provide the most accurate and helpful response.}

SS writes

Hi Ron. My name is SS

I’m writing from Quebec, Canada

My mother in law gave me this clock before she passed. A while ago.

I’ve been doing some research to see who would appreciate this clock and what is the value.

I’ve been looking on sites but I don’t see this original shape. I was wondering if it would be possible to give me an idea of the value and who to sell it too.

Thanks SS

My Reply:

Thanks for your email, SS. I am just back from vacation and catching up on email queries, so, I apologize for the delay.

What you have is a clock made by the Pequegnat Clock Company of Kitchener Ontario. It is a clock that is part of their Maple Leaf series of kitchen clocks. Here is an article I wrote earlier this year describing clocks in the Maple Leaf series.

The Pequegnat story & the Maple Leaf series of kitchen clocks

Your clock has value and most Pequegnat clocks are sought after by collectors. It would be valued in the $200-$300 range.

Here is another article I wrote that might give you some ideas on how to sell your clock.

Selling your antique clock – some simple and effective strategies

Hope this helps.

Ron

October 10, 2023

Tick Talk Tuesday #50 – My mother-inlaw gave me this clock

^{Tick-Talk Tuesday is dedicated to addressing readers’ letters and comments related to clock issues, challenges, and recommendations for specific clocks. In cases where the comments and questions are particularly challenging, I seek advice from my fellow clock enthusiasts to provide the most accurate and helpful response.}

SS writes
“Hi, Ron. My name is S and I’m writing from Quebec Canada.

My mother-in-law gave me this clock before she passed a while ago.

I’ve been doing some research to see who would appreciate this clock and what its value is.
I’ve been looking on sites but I don’t see this original shape. I was wondering if it would be possible to give me an idea of the value and who to sell it to.

_{The rear of the clock shows a partial label}

My reply

“Thanks for your email. I am just back from vacation and catching up on email queries, so, I apologize for the delay.

What you have is a clock made by the Pequegnat Clock Company of Kitchener, Ontario (Canada). It is a clock that is part of their well-regarded Maple Leaf series of kitchen clocks. Here is an article I wrote earlier this year describing clocks in the Maple Leaf series.

The Pequegnat story & the Maple Leaf series of kitchen clocks

_{The Pequegnat story & the Maple Leaf series of kitchen clocks}

Your clock has worth and most Pequegnat clocks are sought after by collectors. It would be valued in the $200-$300 range.

Here is another article I wrote that might give you some ideas on how to sell your clock.

Selling your antique clock – some simple and effective strategies

_{Selling your antique clock – some simple and effective strategies}

Hope this helps.

Ron”

September 19, 2023

Antiquvintageclock visitors come from all over the world

The dashboard that forms part of the WordPress package offers a fascinating array of statistical information. It empowers me to track the viewership of my articles and gain insights into readers’ interests, as indicated by the number of clicks, which serves as a valuable measure of engagement.

So far in the year 2023, antiquevintageclock.com has received an impressive total of 67,875 visitors, who collectively generated 124,006 page views. On average, each visitor explored the site with 1.83 views, indicating a significant level of interest and engagement.

Visitors came from a diverse range of 162 countries. So, let’s take a closer look at the top ten countries that contributed to the website’s viewership:

USA
United Kingdom
Canada
Australia
India
South Africa
New Zealand
Ireland
Netherlands
Germany

Google Analytics also enables the author to monitor real-time activity. For example, in a snapshot taken as this article was being written, there were visitors from America, France, Kazakhstan, and Australia.

It’s interesting to note that the website’s origin in the beautiful province of Nova Scotia, Canada, has attracted a significant portion of its visitors from English-speaking countries. This likely indicates a shared interest in exploring the world of antique and vintage clocks.

To encourage a global audience, this blog features a convenient language translation applet on its front page, enabling visitors to explore its content in the language of their choice. This user-friendly feature fosters a more inclusive and enjoyable experience for readers from diverse linguistic backgrounds.

July 28, 2023

Clocks at our summer retreat

Taking a look at this Ansonia cotteg clockwith the dial off

At our seasonal cottage located in central Canada, we enjoy displaying a small selection of clocks, during the summer months.

The first clock, displayed for a number of years, was a Danial Dakota time and strike clock, which we had converted to a quartz movement. This clock, originating from the 1960s, incorporated Chinese design elements that were inspired by American clocks of that era. It required minimal maintenance and provided very good accuracy.

To operate, it relied on a “C” cell battery. This chiming clock offered both Westminster and Whittington chimes, with my wife and I favouring the Whittington chime.

However, after a period of time we grew weary of the clock’s artificial electronic musical tone, and thus we decided to replace the Danial Dakota clock with a proper mechanical clock.

The Mauthe time and strike box clock we acquired as a replacement at the cottage features a raised maple leaf on its crown. This detail leads me to believe that it was likely sold under a Canadian brand, possibly marketed specifically for a department store or jewellery store. The distinctly Canadian touch with the maple leaf emblem, adds to its charm and appeal in our Canadian cottage setting.

_{Mauthe box clock with maple leaf emblem on the crown}

Next to the box clock is a captivating oak-cased gallery clock produced by the Empire Clock Co. of England. It was acquired through an auction in Nova Scotia and boasts a unique feature — a 10-inch dial instead of the more common 12-inch dial seen in similar gallery clocks.

Despite its resemblance to a fusee clock, it operates with a conventional spring-driven mechanism, which means its timekeeping performance is average at best.

Adorning the wall of our sunroom is a familiar time-only schoolhouse clock that was recently gifted to me. It features a sizable 12-inch Roman Numeral dial and a pendulum visible through reverse-painted glass.

Although it has a few minor veneer imperfections that I plan to address later this year, I have already examined the movement and confirmed its excellent condition. After re-oiling it, I carefully placed the movement back into its case.

Displayed in our family room is a Hermle clock that harkens back to a nostalgic design known as the “wag-on-a-wall” style. This clock operates on a weight-driven mechanism and includes both timekeeping and striking functions. It emits a delightful bim-bam sound by striking on three rods.

The design aesthetic of this clock strongly resembles the clocks manufactured in the 1960s, which aligns with its likely production period. While it possesses a plain and unadorned appearance, it carries a certain charm and serves as a reminder of that era.

Among our collection of cottage clocks, we have a New Haven ogee-style clock that operates on a 30-hour time and strike mechanism. It is smaller than a conventional ogee clock and might be referred to as a mini ogee standing at just 18 inches high.

From afar, it presents an appealing appearance, capturing one’s attention. However, upon closer examination, it becomes apparent that the clock has undergone a removal of its veneer at some point in its history. The absence of the veneer adds a touch of character and reveals the clock’s journey through time, offering a glimpse into its past.

Finally, a well-worn 30-hour cottage Ansonia clock graces a bedroom dresser.

Despite its visible signs of use, this clock continues to perform well, a testament to the remarkable engineering employed by the clock’s manufacturers. Craftsmen at the time anticipated the rigours of wear and tear, and their foresight in creating such durable movements showcases their longevity.

Clocks at our summer cottage not only serve as functional timekeepers but also carry with them a unique charm and nostalgia.

Each clock tells its own story, displaying the marks of time and the craftsmanship of its makers. Whether it’s the captivating gallery clock with its distinctive dial or the familiar schoolhouse clock with its endearing imperfections, these clocks create a harmonious blend of functionality and aesthetics within the cottage.

As their hands tick away the hours, they remind us to slow down, appreciate the present moment, and savour the timeless tranquility of a summer retreat.

July 25, 2023

How to Display an Antique Clock in Your Home

In this blog post, we’ll share practical tips on how to incorporate antique clocks into your interior decor. We’ll discuss strategic placement, creative styling techniques, and ways to create an eye-catching focal point.

Make your antique clock the star of the show by displaying it in a prominent location where it can take center stage. Surround it with complementary decor pieces such as vintage books, elegant candle holders, or framed photos to create an enchanting vignette that enhances the clock’s charm.

Kienzle clock on display with Ingraham Huron — _{Kienzle World time clock on left and Ingraham Huron balloon style shelf clock on right}

It’s best to limit the number of antique clocks in a room to one or two to avoid clutter and maintain a visually pleasing space. By creating a focal point for your antique clock, you’ll effortlessly draw the eye and showcase its timeless beauty.

However, some clock collectors understand the importance of presentation when displaying their collections. While it’s generally recommended to avoid placing multiple clocks in one location, some collectors choose to showcase their entire collection together. In such cases, grouping the clocks based on maker, style, type, vintage/age, or country of origin can create a cohesive and visually appealing arrangement. Thoughtful and well-planned presentations with a distinct theme running through them tend to be more successful than haphazard and confusing displays.

It’s common for collectors to set limits on the number of clocks displayed and running at any given time. Some clocks may be allowed to stop for a “break” while others continue to run continuously. Occasionally changing the location of clocks can add variety, but it’s important to consider the sensitivity of certain clocks to being moved.

_{Trio of clocks representing 3 time zones}

For example, in one photo, there are three prominently displayed clocks in a large room, including a 2-weight Gustav Becker clock from 1902, a Seth Thomas round-top cottage clock, and an Ansonia short-drop octagon clock. The arrangement allows the clocks to command attention without overcrowding the space.

Front room collection — _{Clocks displayed in the living room}

Another option is to confine the collection to one room, while others prefer to have clocks distributed throughout the house. The choice depends on personal preference and the tolerance of one’s partner.

In an entrance hallway, the Ridgeway tall case clock shares space with an Arthur Pequegnat Canadian Time wall clock. The limitations of the hallway restrict the number of clocks displayed.

The kitchen features a U.M. Muller time and strike wall clock, which serves as a reliable timepiece for the household.

Lastly, a Mauthe Westminster chime mantel clock sits atop a 1947 Stromberg Carlson console radio in the dining room, adding a touch of elegance to the space.

Arranging a clock collection requires thoughtful consideration, care, and attention. It’s essential to find a balance between showcasing the clocks and maintaining a visually pleasing and harmonious environment. Each placement decision contributes to the overall aesthetic and impact of the collection within the home.

July 21, 2023

The Schoolhouse Clock: Unveiling its History

The origin of the name “schoolhouse clock” is not well-documented, and it appears that the term was not used during the time these clocks were made. Instead, it was later coined by collectors to describe a particular style of clock commonly found in school settings.

_{Gilbert Admiral with calendar function}

Schoolhouse clocks were the standard design for early North American schoolhouses due to their larger, easy-to-read dials. They were widely hung in schoolrooms across Canada and often had simple time-only movements, although some versions included a calendar function or time and strike movements. These clocks had a utilitarian look and were known for their durability.

_{Ansonia Schoolhouse Clock} _{with 12-inch dial}

The design of schoolhouse clocks is believed to be influenced by English drop dial fusee clocks, which were produced in the late 18th and 19th centuries. Drop dials closely resembled schoolhouse clocks and featured conical constructions with a chain or gut line pulled by a mainspring barrel, providing even power release for improved accuracy. Complicated movements such as these did not find their way into inexpensive mass-produced American and Canadian schoolhouse clocks.

When purchasing a clock, the author always asks the seller about its history and provenance.

In the case of the Sessions Drop Octagon wall clock pictured above, the seller had acquired it from a decommissioned one-room schoolhouse in Springhill, Nova Scotia. The clock, dating back to the 1920s, features a solid oak case, original hands, a pressed brass pendulum bob, a solid brass bezel, and a tin dial pan with stenciled lower glazing. While the paper dial showed signs of discoloration and wear, the clock was in reasonably good condition for its age.

Upon bringing the clock home, the author discovered that it ran for only a short time before stopping. A rubbing sound around the pendulum area indicated that the pendulum bob was hitting the inside of the case. After correcting a bent crutch rod, cleaning the movement, and making some adjustments, the clock started running properly. The author considered replacing the paper dial, which had brownish spots from prolonged exposure to moisture but decided to keep it as part of its history.

Time-only movements, like the one in this schoolhouse clock, are relatively easy to work on, making them suitable for beginners in clock collecting and repair.

While the exact origin of the term “schoolhouse clock” remains uncertain, it has become a permanent part of the clock collector language. These clocks, with their distinct style and large dials, were commonly found in early North American schoolhouses and have since gained sentimental value and recognition among collectors.

July 14, 2023

Exploring Factors Behind the Recent Increase in Clock Equipment Prices

While there has been a minimal uptick in clock prices, at least as far as the garden variety of common antique clocks is concerned, the cost of clock repair equipment had increased dramatically.

The increase in the cost of clock repair equipment can be attributed to several factors that may contribute to the significant rise in prices. Following a discussion of the factors I will present a case in point.

Rarity and Specialization

Clock repair equipment, especially those designed for antique and specialized clocks, may have limited production or availability at any given time. However, during the Covid years demand for specialized equipment virtually evaporated. Given the lull in manufacturing the restart costs of producing new equipment have increased. Scarcity and specialization will drive up prices. The relatively small market size can contribute to higher prices as manufacturers may need to recover their expenses with a limited number of sales.

Manufacturing Costs

The cost of raw materials, labour, and overhead expenses involved in producing clock repair equipment has risen over time. Factors such as inflation, increased demand for certain materials, the scarcity of raw materials, and changes in manufacturing processes contribute to the overall increase in costs.

Technological Advancements

As technology advances, new tools, and equipment are developed to cater to modern clock repair techniques. These advanced tools often come with higher price tags due to research and development costs, as well as the incorporation of improved functionality.

Import Costs and Tariffs

Clock repair equipment may be sourced from various regions or countries. Fluctuations in import costs, including tariffs, taxes, and shipping expenses, can impact the final price of the equipment. Changes in trade policies and international relations have influenced the cost of importing these products.

A case in Point

While browsing a Canadian clock supplier’s website in June 2023, I couldn’t help but notice a significant increase in the cost of the Bergeon 6200 Bushing Machine that comes with a toolset. Comparing prices from my previous purchase in 2016, the difference is striking. Back then, I was able to purchase a brand new Bergeon machine with hammers and cutters for around $1200, whereas today, the same machine is priced at $2126, a 77% increase (the 6200 has not been changed significantly), which also includes the reamers and hammers. One might be found at a reduced price of around $1900 on eBay, still a significant jump in price.

Similarly, a box of Bergeon bushings that cost $150 in 2016 now carries a price tag of $325. These price increases have made sourcing a used machine with a toolset at around $700, a more appealing option for someone entering the field of clock repair. However, if the reamers are worn and need replacement, the cost alone would be several hundred dollars if purchased new (all Canadian prices).

Drilling a hole with Bergeon bushing machine — _{Enlarging a hole using a Bergeon reamer}

When evaluating pricing trends in the clockmaking industry, clockmakers and enthusiasts must take into account the changing market dynamics to stay updated.

July 11, 2023

Celebrating Canada Day with family and friends

Finding a way to tie in antique clock collecting and repair to Canada Day celebrations on July 1st is an interesting challenge so I came up with some oddball thoughts the reader might find amusing. So here goes.

Canada Day, at one time known as Dominion Day, marks the anniversary of the Confederation of Canada on July 1, 1867. It’s a day when Canadians honor their country’s rich history and express their patriotism.

As the nation of Canada prepares to celebrate its special day on July 1st, it’s a time for Canadians to come together, reflect on their history, and embrace their shared heritage. And what better way to commemorate this occasion than by exploring the fascinating connection between Canada Day and the timeless beauty of antique clocks?

What is the connection you say!

Antique clocks possess an inherent ability to transport us back in time, evoking a sense of nostalgia and reminiscence. Just like a vintage clock reminds us of eras long gone, Canada Day encourages Canadians to reflect on their roots and appreciate the sacrifices made by those who came before. The celebration of Canada’s multicultural heritage and diverse traditions aligns beautifully with the stories antique clocks hold within their aging wooden cases.

Cherishing our past

Antique clocks remind us that time is a valuable resource, urging us to cherish our past, live in the present, and build a brighter future. Canada Day serves as a reminder to honor the progress made as a nation and strive for continuous growth, just as the gears of an antique clock works in harmony to mark the passing of time.

_{A clock that is older than our Confederation}

To restore and preserve

Antique clock enthusiasts understand the importance of restoration and preservation. Similarly, Canada Day encourages Canadians to safeguard their cultural heritage, preserve historic landmarks, and protect the stories that shaped their nation. Both antique clocks and Canada Day represent the value of cherishing the past and ensuring its vitality for future generations.

The symbolism of time and a promising future

Whether it’s the meticulous craftsmanship, the nostalgic charm, or the symbolism of time, antique clocks and Canada Day share a deep connection that honors the past, celebrates the present, and looks towards a promising future.

So, as you commemorate Canada Day, take a moment to reflect on the timeless beauty of antique clocks and the remarkable story they tell.

And, there you have it.

As for me relaxing with friends and family is the only way to celebrate our most important day of the year.

June 30, 2023

If I had to take one antique clock from a “burning house” which one would it be

We have been facing a challenging spring here in Nova Scotia, as the threat of wildfires has been looming over us.

In May 2023, our community in Nova Scotia has been devastated by the occurrence of two uncontrolled wildfires. The dire consequences of these fires include the evacuation of thousands of individuals and the tragic loss of hundreds of homes.

Residing in a rural area with our house nestled amidst beautiful trees, we can’t help but have a constant awareness of the potential for fire.

While it’s crucial to prioritize safety and well-being in emergency situations, it’s understandable that certain personal belongings/items hold significant value to us. They include ID, cell phones, credit cards, vehicle titles, keys, flashlights, passports, a portable hard drive containing all personal photos, and essential clothing but if I find myself with a moment to select just one antique clock during a speedy evacuation what would it be?

My wife prompted this discussion when she asked, “What clock would you take?

Selecting a specific antique clock to save from a “burning house” is a subjective decision based on personal preferences, sentimental value, and the uniqueness of each clock. However, here are a few factors I might consider when making my decision:

I might choose a clock that holds special meaning to me or my family. It could be a clock that has been passed down through generations or one that has sentimental value attached to it.
I would consider the rarity and historical significance of the clock in question. If a clock’s origins is significant or it is known for its craftsmanship or historical importance, I might prioritize saving such a clock.
If one clock is in better condition or has the potential for easier restoration, it might be a good choice to save.

Here are 5 clocks that would be high on my list and the reasons why. But in the end, I could only take one!

Pequegnat Canadian Time

I have had this clock for a number of years, and have serviced it twice. The clock’s case, on the other hand, has remained untouched and remains in exceptional condition. This particular clock holds a special place in my collection as one of the earliest examples of the eight Pequegnat clocks I own. It spent its life in the waiting area of a train station located 1/2 drive from my home.

Sawin Banjo Clock

Dating back to the 1840s, this exceptional timepiece exemplifies the pinnacle of meticulous movement craftsmanship. While the case and movement do not bear any explicit “Sawin” markings, various indicators strongly suggest that it was crafted by John Sawin himself or one of his associates or apprentices. Notably, this clock stands out for its straightforward construction, lacking side rails or ornate embellishments such as painted tablets or gilt decorations. It is precisely this simplicity in design that captivates me, as it allows the clock’s elegance and craftsmanship to take center stage.

Junghans Crispis time and strike wall clock

This clock underwent a comprehensive restoration process involving countless hours of work, including disassembling, creating new components, servicing the movement, and refinishing the case. The restoration required a significant amount of labor and attention to detail. The clock holds a captivating story as it was rescued from a house that endured severe destruction during the Halifax Explosion in 1917.

Halifax Explosion – December 6, 1917

Single-weight Vienna Regulator

The sheer beauty of this clock makes it incredibly challenging to part with. Its design epitomizes the finest qualities of the 1880s Vienna style. Unlike the later Viennese clocks, which often leaned towards ornate and ostentatious features, the clocks from this particular period maintain their elegance and embrace a more refined and understated aesthetic. The clock’s classic, simple lines are a testament to the enduring allure of the Vienna style during that era.

Arthur Pequegnat Canadian Time

It is quite possible that this clock was located in a train station or some other commercial setting, given its robust construction and durability designed to withstand potential mistreatment. Additionally, its timeless design features are reminiscent of the classic lines commonly associated with the 1920s era. The clock’s sturdy build and elegant aesthetics perfectly capture the spirit of that period, adding to its overall charm and appeal.

E. Ingraham Huron

This clock resided in the charming vicinity of Bridgewater, Nova Scotia. It came into our possession during a challenging period for a couple undergoing a difficult separation, as sentimental items often find their way to new homes in such circumstances. Among the clocks in my collection, this one stands out as one of the few that underwent professional servicing, ensuring its optimal functionality. Notably, this clock holds a relatively rare status, being produced by the E. Ingraham Clock Co. during the brief span of two years, between 1878 and 1880.

And now it boils down to the one to choose?

Although I hold great admiration for all of these clocks, if I were constrained by space and could only choose a single one to take with me, it would have to be the Junghans Crispi. As mentioned earlier, this clock embodies the qualities that I value, such as its exceptional craftsmanship and timeless appeal. Its unique design, combined with the renowned Junghans brand, makes it a standout choice in the collection. Given the limited space, the Junghans Crispi would be the clock I couldn’t bear to leave behind, as it represents the epitome of my preferences and holds a special place in my heart.

June 16, 2023

Timeless Treasure: My First Arthur Pequegnat Clock Discovery

Clock face Arthur Pequegnat Canadian Time clock

During my article review this week, I stumbled upon my first-ever blog post from 2015 about my fortunate discovery of an Arthur Pequegnat clock in a nearby antique shop. It was an exciting experience for me, and I was thrilled to share it with my readers.

This was my first Arthur Pequegnat clock whihc was the second edtiiion of the Brandon model. The second edition was made from 1917 to 1941. The first edition of the clock, which was produced until 1916, had similar dimensions but a more ornate frame around the dial bezel.

The Arthur Pequegnat Clock Company’s Brandon II model is a simple clock and was one of their most sought-after designs. It was primarily used in Canadian schoolrooms and office settings during the 1930s and 1940s.

The clock’s octagonal shape and short drop make it a recognizable design, and it is often referred to as a schoolhouse clock. Schoolhouse clocks were a popular type of clock used in schools during the late 19th and early 20th centuries, characterized by their simple yet sturdy design and often featuring a visible pendulum.

Schoolhouse clocks were usually time-only, as there would be other methods such as bells or alarms to mark key points in a typical school day. If placed in an office environment, a strike train would be too distracting for employees. Brandon models also came with calendars, a useful feature for both school or office.

_{Time-only Brandon with Calendar} _{and “Regulator” decal}

Both the case, made of quarter-sawn oak, and the brass movement were produced by the Arthur Pequegnat Clock Company in their small Kitchener factory until 1941. The company stopped production abruptly due to brass shortages during the Second World War.

The time-only movement is relatively simple with few gears and little that can go wrong. It was designed to be reliable, dependable, and able to withstand the abuse of a school or office environment.

_{Arthur Pequegnat Brandon time-only movement}

I purchased this clock from an antique collector who had owned it for a number of years. He decided to sell it in his antique shop in Great Village, Nova Scotia, and I found the price to be reasonable. The case, face, and bezel are all in excellent condition. However, the clock had an annoying squeak that suggested something was wrong. After investigating, I discovered that the first wheel had considerable pivot hole wear.

Regrettably, due to my lack of expertise and tools at the time, I couldn’t repair the clock on my own. I had to take it to a horologist in Halifax, Nova Scotia, who performed the required repairs. The clock needed five bushings, a thorough cleaning of the mainspring, and oiling of the movement. Following the necessary repairs, the clock has been consistently dependable and has required only an inspection and re-oiling two years ago.

Since then, I have acquired eight more Arthur Pequegnat clocks and have since gained the skills to service each of them myself.

April 28, 2023

The Pequegnat story & the Maple Leaf series of kitchen clocks

The Pequegnat name may not be familiar to international readers but it was a significant Canadian clock company that manufactured both movements and cases beginning in the early 20th century.

The Pequegnat Clock Company was a Canadian clock manufacturer that operated from 1904 to 1941. The company was founded by Arthur Pequegnat a Canadian immigrant who brought his family from Switzerland to begin a new life in Canada.

Pequegnat was a skilled clockmaker and entrepreneur, and he saw an opportunity to start his own clock company in Kitchener (then Berlin), Ontario. But the story actually begins prior to 1904.

In 1897 Arthur expanded his Berlin Jewelry shop to include the manufacture of bicycles. However, by 1904, with the decrease in the demand for bicycles, Arthur began to re-focus on the clock industry by manufacturing his own clock movements at his Berlin Bicycle Manufacturing plant and the motto, “Buy Canadian – Pequegnat clocks are better than foreign-made ones”” struck a chord with Canadian buyers.

At first, the wooden clock cases were made by local furniture makers, however, in time, he manufactured his own clock cases.

Pequegnat Clock Company produced high-quality clocks, and its products quickly gained a reputation for their accuracy and reliability. The company produced a wide variety of clocks, including wall clocks, mantle clocks, and grandfather clocks.

During the early years, the company faced a lot of competition from American clock companies, but Pequegnat was able to differentiate his products by designing and manufacturing unique clock cases that appealed to Canadian tastes.

The company continued to grow, and by the 1920s, it had become one of the largest clock manufacturers in Canada.

The Great Depression hit the Pequegnat Clock Company hard, and the company struggled to stay afloat during the 1930s. In 1941, with brass in short supply as a result of the war effort the company was forced to close due to financial difficulties, and its assets were liquidated.

Despite its relatively short lifespan, the Pequegnat Clock Company played an important role in the history of Canadian clock manufacturing. The company’s clocks are still highly sought after by collectors, and its products are considered some of the finest examples of Canadian clockmaking.

The Maple Leaf – a symbol of pride

The maple leaf slowly caught on as a national symbol in 1868 (the year after Canada’s Confederation) as it was included in the coat of arms of Ontario and the coat of arms of Quebec and added to the Canadian coat of arms in 1921. The maple leaf is a symbol of our national identity.

_{Arthur Pequegnat Maple Leaf kitchen clock; the “fan top”}

Canadian readers and perhaps those abroad with a connection to Canada would instantly recognize the maple leaf as distinctly Canadian.

Cashing in on Canada’s identity as a nation, Pequegnat saw the value in naming clocks after Canadian cities, cities such as Stratford, London, Toronto, Moncton, Montreal, and so on. Indeed, most homes and businesses in Canada had a Pequegnat clock.

_{Arthur Pequegnat Maple Leaf kitchen clock; the “round top”}

Berlin, Ontario was re-named Kitchener Ontario in 1916, due to anti-German backlash during WW I. This becomes a useful tool when dating Pequegnat clocks as labels, movements, or dials marked “Berlin” date the clock to 1916 or earlier, and those marked “Kitchener” are 1916 or later. However, many clocks had a long production life and it is difficult to date any Arthur Pequegnat clock precisely as there were no production numbers on the movements.

Pequegnat’s interpretation of the kitchen clock

The Maple Leaf series was Pequegnat’s interpretation of the popular American kitchen clock.

_{Arthur Pequegnat Maple Leaf kitchen clock; the “curly top”}

The Maple Leaf Series was a line of clocks produced by the Pequegnat Clock Company of Canada in the early 20th century. The series was named after the maple leaf, a powerful symbol of Canada.

The Maple Leaf Series was first introduced in 1911, and it quickly became one of the company’s most popular product lines. The series included several different models. The clocks were made with high-quality materials and brass movements.

There are 2 notable features of the Maple Leaf Series. One was the clock tablet, which featured a stylized array of 36 maple leaves framed by half moons and with an opening to display the pendulum bob. Why the number 36? In some cultures, it is considered a lucky number.

The second feature was a brass maple leaf pendulum bob.

The clocks in the Maple Leaf series did not have specific names and are referred to by collectors as the pointed top, the round top, the fan top, the curly top, and so on.

_{The Maple Leaf series of Pequegnat kitchen clocks (photo courtesy of The Canadian Clock Museum)}

The clock depicted above may or may not belong to the Maple Leaf series but the maple leaves within the tablet design are considerably more stylized, and the edging is understated. Like the Canuck pictured below, this design could be a variant.

Arthur Pequegnat Maple Leaf Pointed Top — _{Arthur Pequegnat Maple Leaf kitchen clock; the “pointed top”}

The dials were typically paper on tin and some had a gold center accent.

Many would not consider the Canuck to be a “Maple Leaf” kitchen clock though some variants had a maple leaf tablet. The Canuck also stood out from other kitchen clocks due to its use of steamed pressed oak in its construction.

The Maple Leaf Series was a significant part of the Pequegnat Clock Company’s success, and the clocks from this series are still highly prized by collectors today.

Overall, the Maple Leaf Series represented a major contribution to the Pequegnat Clock Company’s prosperity, and its models remain a sought-after collectible for clock enthusiasts.

April 21, 2023

Best clock acquisition of 2022

Well, it’s that time of the year. What is my best clock acquisition of the past year? You can decide for yourself and leave a comment but I will reveal my favorite at the end of the post.

As a clock hobbyist, I have had little difficulty locating interesting clocks and every year I have managed to find a winner or two. 2022 was no exception.

In the early days of collecting, time and strike vintage mantel clocks were my principal focus with the goal of taking them apart and making them work, an important part of my learning. Many of those clocks have been either sold or gifted. I have shifted my focus toward collecting interesting clocks, rare clocks, clocks that have a special provenance, and growing my collection of Canadian-made clocks.

My wife is my best clock finder. Our discussions may go something like this; “did you see that wall clock on Facebook/xxx auction house?”. “Let me see. Yeah, it looks good, what do you think? Make an offer?” and off we go. Sometimes I will accept the offer from the seller without negotiating because it is a fair price but there are times when a little wheeling and dealing takes place prior to the sale.

In no particular order, here are my finds for 2022.

Fusee gallery clock

The clock is also called a dial clock in England which is where it was made. There are no markings anywhere on the clock save an obscure trademark that I have been unable to identify. It is a time-only fusee clock with a 12-inch dial, a very common size. It might have had a chain drive at the beginning of its life but it now has a cable. I have not serviced this clock because I don’t know enough about fusee movements, particularly the method of preloading the powerful mainspring.

E N Welch marine clock

This 30-hour spring wound clock with a hairspring lever escapement simply tells the time. It was made in the 1870s and perhaps earlier. It has been serviced, bushed, and cleaned, but my challenge at the moment is setting up the hairspping. It will work but not well.

Hamilton clock co ogee

_{Hamilton time and strike ogee clock, Canadian made}

Acquired in the spring of 2022 this ogee clock was made in Hamilton, Ontario (Canada). The movement was serviced but the case challenged my veneering skills. It looks quite presentable now but was in poor condition when I bought it.

Jerome and Co. Rose Cottage clock

Quite honestly I was going to throw the case out after having serviced the movement. It simply looks too far gone. However, I have accepted the challenge of bringing back this clock to its former glory. So far it is a work in progress.

Jauch calendar clock

From a distance, this clock looks good but a closer examination reveals a cheaply made time-only movement and an equally inexpensive pine case. It is clear that this German company was attempting to cash in on the antique American schoolhouse clock that was popular in the 1970s.

Wag on the wall

This has a well-made German movement, possibly by Mauthe or Hermle. It is a time-and-strike weight-driven clock and keeps very good time. Its only negative is that it has a cheap 1960s look about it but the only thing missing is a bottom middle finial.

Sessions Grand Assortment

Perhaps the ugliest gingerbread clock ever made. The photo is the exact clock I worked on two years ago since the clock is apart at the moment and I have stripped down the case (a last resort).

Sessions Mission clock

I like this clock not only because it is a 10$ thrift store find but it has very nicely styled mission clock and it works very well, keeping decent time for a spring-driven clock.

Empire gallery clock

_{English gallery clock} _{with 10-inch dial}

I was hoping this was a fusee clock when I bid on it on an online auction in the spring of 2022 but it is a spring-driven 8-day clock with a fairly robust movement that was intended for commercial use, a store, an office environment perhaps.

Daniel Pratt Jr woodworks clock

I have a couple of Danel Pratt woodworks clock. Unfortunately, this one is missing its topper. Servicing woodworks movements takes special care and attention and I may tackle this clock in the spring.

Ansonia 30-hour parlour clock

I seem to gravitate toward 30-hour clocks. This is a time-and-strike clock and is in decent condition requiring only a few touchups.

My favorite?

Well, it has to be the time-only fusee which is probably why I subconsciously placed it first on the list. It well built industrial-strength clock that was designed to last for years. It looks great on any wall, is very quiet, and quite accurate which is what fusee movements are known for.

February 14, 2023

After veneer repairs, the Hamilton ogee case is finished

Just before Christmas 2022, I published an article on a Hamilton Clock Co. 30-hour ogee that I won at auction earlier in 2022. I had been delaying repairs on the case for months and finally found the time to tackle the veneer work.

I seem to be strangely attracted to ogee clocks, this is my fifth acquisition over the past 6 years and I think that’s it, no more except for that seemingly rare-ish eight-day version from any American maker.

The Hamilton Clock Co is in no way associated with any American company or companies and is a wholly home-grown Canadian Company that made clocks in the late 1880s. in Hamilton, Canada that were styled after American ogee clocks of the time.

Hamilton Clock Co. ogee – a dull and tired case needs help

_{December 2022 article}

The clock was complete with weights, pendulum bob, original hands, dial, and even the top dust caps which are often missing from these old clocks. The movement was in good shape and other than installing 5 new bushings to address enlarged pivot holes there was no significant wear. The cables were replaced with braided nylon and the pendulum suspension spring/leader was also replaced.

The case needed veneer remediation, particularly the top corners. The entire side trim piece required a considerable amount of work and the bottom veneer strip was missing altogether.

The next photos showed how hopeless the top right and bottom sections appeared when I first received the clock and had a good look.

Some might argue that the case should be left as-is since the repairs however poorly are part of the history of the clock. This is the never-ending conservation/restoration argument that arises. Preserving some clocks as they are is certainly important but this was not an expensive clock and in this situation, I take the view that a repair will not only improve the appearance of the clock but enhance its desirability if completed correctly.

Step 1 – cleaning

The case is solid and no structural repairs are required.

My go-to cleaner is Murphy’s Soap which I cut half and half with water. I begin by cleaning the case which unfortunately means removing some of the shellac. This is unavoidable but there is enough shellac remaining that the case would not be stripped in the true sense of the word. I removed the right side trim completely to work on it separately. The plan was to glue it and the bottom trim piece back on when I was finished with the veneer repair.

Step II – veneer work

I usually keep a supply of veneer harvested from old clocks. I am not the best judge at identifying wood types and find myself confusing Rosewood with mahogany at times but I make a comparison based on what I have and what seems to look the best by comparing colouring and grain and for the most part, it looks acceptable when the job is completed.

I have also learned recently that makers will occasionally use different types of wood veneer on the case surfaces at the time of manufacture and simply dye/tint them to match. In fact, while cleaning the dust caps a bit of colouring transferred to the rag and it looked very much like ocher.

_{Hide glue} _{on a heating pad to maintain the temperature}

Medium-strength hide glue is mixed prior to the project. The working temperature is about 160-170 degrees Fahrenheit.

Painter’s tape is used to ensure that the ends are not damaged during the cutting of the veneer.

An artist’s or carpenter’s blade is used. Ensure it is good and sharp, you don’t want the blade pulling on the veneer as you cut.

Depending on the bonding strength of the hide glue you have a limited amount of time to secure the veneer in place.

_{Clamping the veneer to the trim strip}

Have plenty of clamps large and small on hand.

_{Attaching the veneer strip to the case}

Once the veneer is attached to the trim piece and allowed to dry for 24 hours it is time for gluing and clamping the right and bottom border strips to the case.

Step III- – the shellac finish

Once the case has dried for 24 hours the shellacking can begin. I use an artist’s brush for the application of shellac using long and even strokes. For larger areas, one might opt for a French polish technique which is essentially a piece of cloth shaped into a ball and wrapped into another piece of cloth and dipped into the shellac. The main idea is to dip and apply the shellac using smooth even strokes.

I generally apply 2-3 coats of shellac, and between coats smooth the surface with 4-zero steel wool.

Final thoughts

I am certainly not the foremost expert in veneer repair but along the way, I have mastered the fundamentals. Each project offers its unique challenges and this one was no exception.

I was somewhat surprised that after cleaning the left and right trim pieces and shellacking both that the right side and bottom trim piece were somewhat lighter than the left side. However, the new pieces added to the right trim section matched quite nicely. This shows up more dramatically in a photograph. But I think the lighting had a lot to do with the contrast. The light and shadows of the clock combined with the sun coming in from the right side of the clock seem to make the difference more pronounced.

It is also possible that the right side was tinted to match at one time and cleaning removed the tint. Comparing it to other ogee clocks in my collection for some there is a slight variation from side to side and top to bottom but not as striking as on this clock case.

_{Light source from the left, the contrast is not as striking}

At the end of the day, I am pleased with the final result. I would imagine that in time the new or lighter sections of the case will darken somewhat.

I can now add it to other Canadian clocks in my collection.

January 24, 2023

Hamilton Clock Co. ogee – a dull and tired case needs help

Should antique clock cases be refinished or rejuvenated? It can be a judgement call. I am all for patina and preserving an old clock case but there are times when certain amount of intervention is practical from an aesthetics and resale point of view.

There is a certain philosophical argument among collectors who believe on the one hand that any intervention is sacrilegious while others feel that some amount of intervention may be necessary to preserve an antique clock.

I won this Hamilton Clock Company 30-hour ogee clock at auction in the spring of 2022 and only now have had a chance to work on it.

I was not specifically looking for a 30-hour ogee as I have 6 already (and who needs another 30-hour clock) but as this clock was made in Hamilton Ontario, Canada it is special to me as adding Canadian clocks is a prime goal as a collector.

_{Auction photo showing the lower acid etched tablet}

A brief history

The company was established in 1876, after the failure of the Canada Clock Company (version 1) in Whitby, Ontario. Using a new factory building and the original production machinery the second company, the Hamilton Clock Co. was formed by three principles, James Simpson, George Lee, and J. F. Collins.

The Hamilton Clock Company made a valiant effort to provide clocks for the Canadian market, in competition with the huge U.S. clock factories in Connecticut that already dominated the market.

Ogee clocks were manufactured at Hamilton, and these were identical in construction to those that had been made at Whitby with veneered pine cases. After four years the company went bankrupt but was shortly resurrected as the Canada Clock Company (version 2), again using the same Hamilton production facilities. Clock production ended in the mid-1880s and it was not until a new Canadian-owned clock company emerged in 1904 (the Pequegnat Clock Co.) in Berlin, Ontario that Canadian-made clocks resumed production.

It is tempting to group the three companies into one, but the design focus of each company separated them from each other, the early company focused on 30-hour movements and simply styled mantel clocks while 8-day wall clocks and more ornate mantel clocks were a feature of the later company.

The case

Yes, it is dulled and tired and it has had a rough life. These clocks are handed down from one owner to the next and in the process they undergo changes. Some of the changes are reversible and some are not. Luckily this clock can be revived and brought back to life.

There are veneer losses, particularly on the two upper corners and the trim strip along the right side. The bottom strip is missing completely. So the challenge is to replace missing veneer with new and old stock but the end result is not always perfect.

Let’s see what I can do with the case.

December 23, 2022

The time-only clock – simplicity without the noise

People often tell me that they could never have an old-fashioned antique clock in their home because of the noise. And by noise, they are not so much disturbed by the ticking sound as they are about the sound a clock makes on the quarter, half, or on the hour, in other words, a striking or a chiming clock.

But, the ticking sound might also be bothersome. Some of my clocks are loud tickers, they can easily be heard in the next room. Some, on the other hand, are silent tickers, and the only way to determine if they are running is to approach them or observe the movement of the minute hand.

I completed work on a German Jauch time-only clock the other day and could not believe how quiet it was. This is not an expensive clock by any means. So cheap in fact that I only paid $1.65 for it, but that’s another story. It is not rare either, thousands were made but it was engineered to be very quiet.

Of the 90+ clocks I have in my collection, 20 are time-only, that is they are not striking or chiming clocks, they simply tell the time. And it is their simplicity that intrigues me. Many are wall clocks, a couple are calendar clocks, most are antiques and some are vintage. Clocks in and around bedrooms are time-only and all 4 kitchen clocks are time-only as well.

_{Three clocks located in our kitchen that are set to 3 time zones}

Here are eight of my time-only clocks (starting with the Jauch above) and a story behind each one.

This is probably one of the more expensive wall clocks in my collection. It is an unnamed Vienna-style regulator.

It is in its original finish. The finials on top might have been added but it is difficult to tell. Otherwise, the clock is complete. It was found on a local online for-sale site and the seller did not budge much from his asking price but it is one of my favorite clocks. Sadly, I do not know anything about its history.

I picked up this clock while on vacation in the USA. It was found in an antique mall in Michigan. A very simple clock, cheap and it runs very well though because it is spring driven it is not one of my better timekeepers. The ticking is just soft enough to be soothing which is why it is the only clock running in our bedroom.

_{Federal-style banjo clock, possibly John Sawin CA.1840}

This Federal-style weight-driven banjo clock was discovered at a yard sale near my home. The seller was trying to steer me toward a 30-hour clock for an outrageous price that I knew was worthless but they obviously did not know the value of this Federal-style banjo clock so I bought it instead for a ridiculously low price.

It was a family clock held by a collector in Wolfville, Nova Scotia (Canada) for a number of years until he passed away. It is a weight-driven clock, very accurate, very well constructed, and very well preserved. The dial glass was broken and other than that, it came as you see it in the photo.

This 8-day time-only clock came from a business establishment in Toronto, Ontario (Canada). It was well cared for, serviced regularly, and very accurate. The Seth Thomas Regulator #2 was also a popular choice for train stations across North America.

This mahogany-cased gem is an Arthur Pegugant Moncton 15-day double spring time-only clock that was a popular choice for business establishments. It is also from the Toronto area.

_{Gilbert Admiral with calendar CA.1895}

Found in a local antique shop locally this Gilbert Admiral calendar clock looks great on any wall. Unfortunately, I know nothing about it. It could have been either an office or a schoolhouse clock.

Highly sought after this Kienzle World Time clock commands high prices on auction sites. This example is in pristine condition and runs but has not been serviced. It was found in an antique shop in Kazabaszua, Quebec. The clock was designed by Heinrich Möller, chief designer for Kienzle Clock Co. of Germany, and it was considered a higher-end big desk office clock that displays world time zones. I can only imagine an important import-export dealer with this on their desk barking orders to send things here and there.

From a repairer’s point of view, time-only clocks are the simplest clocks to work on since there is not much to them. There is only one train and any repairs are straightforward and far less complicated than clocks with two or three trains. On the whole, they are more accurate, particularly weight-driven varieties because they lack the complexity of all those additional wheels and levers which only serve to add friction to any movement. Perhaps its simplicity is its greatest attraction.

My advice. If you are looking for an antique clock and plan to run it but might be bothered by the noise, consider a time-only clock. You will thank me.

Simplicity without the noise.

November 18, 2022

The Canadian Clock Museum – a must-see for clock fans and museum lovers!

A museum is an institution dedicated to the display of objects of lasting interest or historic value. A museum can display just about anything but The Canadian Clock Museum, located in Deep River, Ontario (Canada) focuses on Canadian clocks or clocks that have a Canadian connection.

Most are mechanical clocks as you would expect but the most extensive collection of (Toronto-based) Snider electric clocks is contained within its walls.

_{This Snider clock is located in the foyer of a Quebec City boutique hotel}

_{Display of Snider clocks in the entry foyer of the museum}

There are static displays that change very little over the years but Curator Allan Symons continues to acquire new and interesting clocks of all types and it seems that in the past two years some large hall and grandfather clocks have been added. Interesting, because they take up a lot of space and space is at a premium in this tightly packed museum.

Despite the museum’s diminutive size, there is a relaxing flow as one explores many manufacturers and thematic displays. It is easy to get lost in the history of the many clocks on display. There is just enough information on the description cards adjacent to each clock to keep the visitor’s interest without getting too deep into the weeds.

Many clocks come with interesting stories that Allan will happily relate but some histories are, unfortunately, incomplete. Clock collectors know that as clocks pass from hand to hand some or all of the history is lost forever.

The clock that intrigued me most in this, my seventh trip to the museum, is a top-of-the-line grandfather clock made by the Blackforest Clock Company of Toronto and donated to the museum. Founded in 1928 by Leopold and Sarah Stossel the Blackforest Clock Company and later the Forestville Clock Company was a prolific producer of clocks for Canadian Homes. Complete clocks were imported from Germany or movements were imported and installed in locally made cases.

The company continued as the Blackforest Clock Company until 1941 at which point the Second World War and the unfortunate association with Germany led to a name change to the Forestville Clock Company. During the war years, movements were sourced from England, France, and the US. As factories ramped up production Forestville resumed importing movements from Germany. Ed Stossel retired in 1979 and the company could not survive much longer without his leadership.

This imposing floor clock stands about 7 1/2 feet tall and is a majestic piece of mahogany cabinetry with carved bonnet and capitals, fluted columns, hand-painted moon dial, carved feet, and a large central finial over a carved head of a young woman(?).

The weights are cable wound by inserting a winding crank in the 3 arbours on the dial face. The case was not made in-house at the Blackforest Clock Co. but by a smaller firm specializing in grandfather clock cases (Westminster Time & Clock Industries from Scarborough, perhaps?).

However, the unique feature of this clock is the Westminster chimes on five tubular bells, one tube extending all the way to the inside bottom of the case. The chime hammers are driven by a large pin drum located on the top of the movement. The sound is not overly loud but melodious.

If you have but a casual interest in clocks there are other displays of interest, one of which is an old phonograph made by the Victor Talking Machine Company, Camden, New Jersey, USA) and sold as the Victrola brand by the Ormes Furniture Company Limited of Ottawa.

Victrola was a brand name for the many table and floor models made by the Victor Talking Machine Company starting around 1927. The new models promoted the latest recordings made via microphone for the first time starting in the mid-1920s.

The museum’s large floor model is one version of the Credenza model.

Starting around 1900, before electricity availability, records were both recorded and played back acoustically. Microphones and electric motors changed the music recording industry.

In the late 1920s, the Credenza was considered a state-of-the-art player for 78rpm records and it was available in either an electric version or a 4-spring wind-up. The museum has the electric version. The fidelity of this stand-up model is remarkable as it capably projects the music into a large room.

Allan played a 78rpm disc recorded in 1951 by Mary Ford and Les Paul, yes the same Les Paul of guitar fame. The song was How High the Moon and the Victrola filled the room despite the limitations of a steel needle (stylus) and an acoustic trumpet (folded 6-foot wood horn).

Not only is the museum worth at least a one-time visit for clock lovers but return visitors will always be rewarded with some new and, of course, fascinating additions.

However, if you are unable to visit the museum Allan will take you on a virtual tour that will no doubt pique your interest to come and enjoy the museum’s many offerings.

October 21, 2022

Sessions wall clock found in a thrift store

I often get letters from my readers that begin with something like, “I picked this up in a thrift store” and marvel at what they find for next to nothing. Quite often the item they snagged at an unbelievable price needs a little love but that is to be expected.

While on our summer jaunts my wife occasionally drags me into the odd thrift store because as she says, you’ll never know what we’ll find” and quite often she’s right. Over the past two or three years, we have bought a few jazz and classical CDs for next to nothing (yes, CDs are back).

Recently we stopped in a small town in an adjacent province to look around. We found a couple of classical CDs and were content to leave when my wife pointed out a mission-style clock hanging behind the cash.

“What’s the price on that? “, I asked. “I don’t know, the boss is in the back” I found him throwing items into a dumpster, obviously things that could not even be given away. “I’m interested in a clock”. “Show me”, he said. We both walked to the front of the store, he looked up at the clock, rubbed his chin, and said, “how about 10 bucks”. I mean, why dicker!

I don’t have a Mission-style clock in my collection and hoped that it was a Canadian-made Arthur Pequegnat, but I knew the hands were not the type used on Pequegnat clocks. Upon first inspection, the only things missing are the winding key and a label which is normally affixed to the backboard.

I thought perhaps it was an Ingraham or Sessions. Once back at home I unscrewed the back panel and identified it immediately as a Sessions movement. Still a good deal. It also tells me that it was made after 1903 the year the sessions Clock Company was formed after a group of investors bought out the assets of the EN Welch Clock Co.

The mainsprings were wound tight. Rather than let the springs down I ran the clock. The time side was fine, a small matter of putting it in beat but the strike side needs a little work. There is nothing wrong with the passing strike on the half-hour but complete silence on the hour. Something is amiss on the strike side. I‘ll give it a nudge and see what happens.

In any event, servicing is in order.

Yes, I picked this up in a thrift store!

September 12, 2022

Wag on a wall – servicing a well engineered movement

This wall clock was gifted to me in the spring of 2022. I have no idea who made the clock, there are no markings on the case or the movement. It was likely sold by the Forestville Clock Company of Toronto in the 1960s and my guess, a Hermle movement. I could find nothing else about it online. I wrote an article in August with first impressions.

The style of the clock is a “wag on the wall”. It is a strange name but basically describes what it looks like it is doing, wagging its tail. A Wag on a wall clock is a clock with the movement enclosed in a small case with a pendulum and weights exposed.

From 1660 to about 1870, the wag-on-the-wall was a very common clock style. It is so named because the pendulum appears to wag on the wall like a dog’s tail. It is also a derivative of the English lantern clock (more closely to a converted one with a pendulum). It was eventually deemed not attractive enough to hang on the wall in many upscale homes, so wooden or glass and wooden cases were added. The long-case or grandfather clock evolved from this early wags-on-the-wall. Wooden cases were used to hide the unsightly weights and cast-iron pendulum.

The style did not disappear as many manufacturers continued making the wag-on-a-wall style clock to this day.

There were several clock assemblers operating in Canada up to the mid-1970s, and it was likely imported and assembled by the Forestville Clock Company of Toronto.

It is a rack and snail movement possibly made by Hermle. The second wheel teeth are larger than one would expect so, a lot of thought went into the design of this movement. I have worked on similar movements in the past though this one is a bit different, specifically the arrangement of the hammer assembly, one main wheel is the reverse of the other, and of course, it is a weight-driven time and strike clock.

Based on my initial observations the movement looks fairly clean despite the tarnished brass but I am expecting minor wear issues commensurate with a 60-year-old mechanical clock.

Disassembly

I took a number of photos prior to disassembly. This is my regular practice and although I have worked on many similar movements though there are always minor intricacies that differ from manufacturer to manufacturer.

To remove the movement from its case, two slotted screws holding the movement to the seat board are released plus, the weight chains must be pulled out. To release the chains the weight hooks must be removed.

The rack and snail assembly, minute wheel, hammer assembly, escapement, and pendulum leader were removed initially and placed in a collection tray. What remained were the wheels and the lifting lever between the plates secured by four pillar nuts.

The gathering pallet arbour and the main arbour are pressure fit. So, when I separated the plates most of the wheels fell out, of course. It can be a challenge for first-time clock repairers but when one works on a few there is a certain logic to the placement and orientation of the wheels.

Assessment of the movement

Because there was generally little wear, I made three decisions. I elected not to separate the central arbour and did not pull the gathering pallet from its arbour. As a result, the plate with two arbours attached was placed in the ultrasonic. I did not disassemble the main wheels which were held together with pressure washers. The main wheel ratchets and chain teeth are in very good condition and the ratchet assembly worked as it should and there was no need to take them apart.

I cleaned up residual oil and dirt around the pivot holes, removed excess oil from the pates, inspected the pivots for wear, and placed all parts in the ultrasonic cleaner. Since I was using a smaller machine than my regular US cleaner, the parts were cleaned in three batches which took a little longer.

_{Older, less efficient ultrasonic cleaner}

I took special care drying the main wheels assemblies and ensured they were operating correctly after they were completely free of any moisture

My wife’s hair dryer came in handy but after cleaning and drying all the parts it fell off the table and broke. Sigh!

The pivots, which are in very good condition, are polished, the pivot holes pegged out and the next step is bushing work. Two bushings are required, the second wheel front plate and the centre wheel, back plate. There is minor wear on those two holes but why not address them while the movement is apart.

Reassembly

As with many rack and snail movements, most adjustments are made after the wheels are installed within the plates but three minor adjustments make the job easier and that is ensuring the gathering pallet is free of the rack, the stop wheel is in the 12 o’clock position and the hammer actuators are free of the star wheel. They must be between the star tips, if not, one of the hammers will catch on a star tip and stall the strike.

Testing

Once fully assembled the next step is installing the chains, weights, pendulum, and testing/adjustment. A small adjustment to the height of the pallets was made after which the clock ran well and continued to run well after 5 days. It is keeping very good time, as expected of a weight-driven movement as any clock that is powered by weights releases its power uniformly through its rated cycle.

Yes, it is a very plain-looking clock that reflects the style of the time (the 1960s) but it might grow on me.

September 5, 2022

Mainspring barrel tooth damage – how does that happen?

Something causes tooth damage. But what?

The example is a Fleet time and strike mantel clock from the 1930s. Fleet Time Company of Montreal, a company that was operating four short years, sourced movements from Germany prior to the Second World War. It was a very common mantel clock sold through department stores across Canada.

I like the step side design and the general simplicity of the clock.

The case was in need of refreshing but the movement looked to be in reasonably good condition and required a good cleaning and I was expecting some wear.

The movement was completely serviced with several new bushings installed. The mainsprings were removed, cleaned, and returned to their barrels.

In this movement, the mainsprings can be removed without disassembling the movement, handy for such things as replacing a broken mainspring assuming, of course that nothing else has been damaged.

During the testing phase, the mainsprings were partially wound. The intent was to see if the clock would run well. Once satisfied that the movement was running as it should I returned it to its case.

I wound the strike side fully and then wound the time side. Just as I was feeling resistance, CLUNK, the arbour turned freely. If it was a broken click or broken mainspring, either one could easily be replaced.

It has nothing to do with the force of winding a movement. Having a mainspring go bad with winding force from a key is rare, in my view.

But mainspring barrel teeth do not simply fall off.

At times it is a mainspring but sometimes something far worse occurs.

It is not uncommon to find secondary damage to the movement, secondary or collateral damage due to the extreme shock that broke or bent the teeth and teeth cannot be straightened.

The main problem area beyond the barrel itself will be the second wheel and possibly the third wheel arbors, leaf pinions and pivots and/or damaged or missing teeth on the second and third wheels and bent or broken pinions.

Fleet second time wheel — _{Fleet second wheel, a bent leaf cannot be unbent}

Is it fixable? Yes, but weighed against the value of the clock, it is just not worth it. It is much more cost effective to harvest parts from another movement.

Given the right equipment, it can be repaired. Once repaired a mainspring must be sourced and although the barrels may be identical, the mainsprings will likely be different.

The solution is locate a donor movement. In the meantime the clock has been put aside.

July 25, 2022

Rate this:

Share this:

Rate this:

Share this:

Rate this:

Share this:

Rate this:

Share this:

Rate this:

Share this:

Rate this:

Share this:

Rate this:

Share this:

Rate this:

Share this:

Rate this:

Share this:

Rate this:

Share this:

Rate this:

Share this:

Rate this:

Share this:

Rate this:

Share this:

Rate this:

Share this:

Rate this:

Share this:

Rate this:

Share this:

Rate this:

Share this:

Rate this:

Share this:

Rate this:

Share this:

Rate this:

Share this:

Rate this:

Share this:

Rate this:

Share this:

Rate this:

Share this:

Rate this:

Share this:

Rate this:

Share this:
